Ethernet Remote I/O, M12 Connector, 4 Dis, 4 Dios, Coating

Mfr # ioLogik E1512-M12-CT-T
Zoro # G4578895

$1,495.99

Free Shipping & Returns

Free Shipping on orders over $50

after you

Free 30-Day Returns

Key Features

Mounting DIN rail (standard), wall (with optional kit)
Sensor Type Wet Contact (NPN or PNP), Dry Contact
Power Consumption 149 mA @ 24 VDC
Dry Contact On: short to GND; Off: open
Shock IEC 60068-2-27

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Moxa
MFR # ioLogik E1512-M12-CT-T
Zoro # G4578895
Country of Origin Taiwan, Province of China
Category Programmable Logic Controllers

Dimensions

144 x 124 x 30 mm (5.67 x 4.88 x 1.18 in)

Details

Mounting	DIN rail (standard), wall (with optional kit)
Sensor Type	Wet Contact (NPN or PNP), Dry Contact
Power Consumption	149 mA @ 24 VDC
Dry Contact	On: short to GND; Off: open
Shock	IEC 60068-2-27
Altitude	Up to 2000 m
Over-current Protection	2.6 A (4 channels @ 650 mA)
Ethernet	1 10/100 Mbps, M12
Over-temperature Shutdown	175°C (typical), 150°C (min.)
EMS	EN 55024, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11; EN 61000-6-2
Safety	UL 508
Common Type	2 points per COM (Configurable DI/Os)
Storage temperature	-40 to 85°C (-40 to 185°F)
Counter Frequency	250 Hz
Isolation	3K VDC or 2K Vrms
Current Rating	200 mA per channel
Over-voltage Protection	45 VDC
Vibration	IEC 60068-2-6
EMI	EN 61000-3-2, EN 61000-3-3, EN 61000-6-4, FCC Part 15 Subpart B Class A
Operating temperature	-40 to 85°C (-40 to 185°F)
Rail Traffic	EN 50155*, EN 50121-3-2, EN 50121-4
Wet Contact (DI to GND)	On: 0 to 3 VDC; Off: 10 to 30 VDC
Digital Inputs	4 channels (channel-to-channel isolation)
Pulse Output Frequency	500 Hz
Type	Sink
Power Input	24 VDC nominal, 12 to 48 VDC
Protection	1.5 KV magnetic isolation
Protocols	Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, HTTP
Configurable DI/Os	4 channels
I/O Mode	DI or Event Counter, DO or Pulse Output
Freefall	IEC 60068-2-32
Wiring	I/O cable max. 14 AWG
Digital Filtering Time Interval	Software Configurable (minimum: 1 millisecond)
Ambient Relative Humidity	5 to 95% (non-condensing)

Description

Ethernet remote I/O, M12 connector, 4 DIs, 4 DIOs, coating, -40 to 85°C operating temperature.
