Active Ethernet I/O Server, 8Tc/4Do

Mfr # ioLogik E2262
Zoro # G4573706

$802.99

Free Shipping & Returns

Free Shipping on orders over $50

Free 30-Day Returns

Key Features

Mounting DIN rail or wall
Millivolt Type Mode: ±78.126 mV, ±39.062 mV, ±19.532 mV; Fault and over-voltage protection: -35 to +35 VDC (power off); -25 to +30 VDC (power on)
Over-voltage Protection 45 VDC
Resolution 16 bits
Current Rating 200 mA per channel

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Moxa
MFR # ioLogik E2262
Zoro # G4573706
Country of Origin Taiwan, Province of China
Category Programmable Logic Controllers

Dimensions

115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting	DIN rail or wall
Millivolt Type	Mode: ±78.126 mV, ±39.062 mV, ±19.532 mV; Fault and over-voltage protection: -35 to +35 VDC (power off); -25 to +30 VDC (power on)
Over-voltage Protection	45 VDC
Resolution	16 bits
Current Rating	200 mA per channel
Safety	UL 508
Vibration	IEC 60068-2-6
Parity	None
Over-current Protection	2.6 A (4 channels @ 650 mA)
Database	Telcordia (Bellcore)
Over-temperature Shutdown	175°C
Freefall	IEC 60068-2-32
Sensor Type	J (0 to 750°C), K (-200 to 1250°C), T (-200 to 350°C), E (-200 to 900°C), R (-50 to 1600°C), S (-50 to 1760°C), B (600 to 1700°C), N (-200 to 1300°C)
I/O Mode	DO or Pulse Output
Accuracy	±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
Storage temperature	-40 to 85°C (-40 to 185°F)
Altitude	Up to 2000 m
Thermocouple Inputs	8 channels
EMS	EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Data Bits	8
Interface	RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Serial Line Protection	15 kV ESD for all signals
Digital Outputs	4 channels
Shock	IEC 60068-2-27
Ethernet	1 10/100 Mbps RJ45 port
Pulse Output Frequency	100 Hz
Protection	1.5 kV magnetic isolation
Isolation	3k VDC or 2k Vrms
Stop Bits	1
Type	Sink
Power Input	24 VDC nominal, 12 to 36 VDC
Input Impedance	1 M ohms
Baudrate	1200 to 115200 bps
Protocol	Modbus/RTU
Power Consumption	160 mA @ 24 VDC
Wiring	I/O cable max. 14 AWG
Operating temperature	Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Ambient Relative Humidity	5 to 95% (non-condensing)
EMI	EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A
Time	341,063 hrs
Protocols	Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Sampling Rate	12 samples/sec (all channels)

Description

Active Ethernet I/O server, 8TC/4DO

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
