Widia

Thread Turning Toolholder, NER123B

product price: $116.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
after you
Free 30-Day Returns

Key Features

  • Shank Shape Square
  • Overall Length 4.5000 in
  • Cutting Direction Right Hand
  • Rake 0 Degrees Axial, 0 Degrees Radial
  • Shank Length 3-3/4"
See all product information
Get 10% Off Your First Order
Real Support From Real People Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
visa mastercard american express discover paypal
Net 30

Product Information

Dimensions

Overall Length 4.5000 in
Shank Length 3-3/4"
Insert Size 3
Shank Height 3/4 in
Shank Width 3/4 in
Depth of Cut 0.2100"
Head Length 19.05mm
Max. Bore Depth 2"
Min. Bore Dia. 2-3/8"

Details

Item Indexable Thread Turning Tool Holder
Shank Shape Square
Cutting Direction Right Hand
Rake 0 Degrees Axial, 0 Degrees Radial
Shank Material High Speed Steel
Coolant Fed Non-Coolant Through
Cutting Application Threading
Insert Style N.3L
ANSI Code NER123B
Center to Cutting Tip 19.05mm
ISO Number NER123B
Insert Holding Type Top Clamping
Toolholder Style NE
Measurement System Fractional Inch

Description

Indexable Thread Turning Tool Holder, Cutting Direction Right Hand, Rake 0 Degrees Axial, 0 Degrees Radial, Shank Width 3/4 in, Shank Height 3/4 in, Overall Length 4.5000 in
