Tycon Systems
24 Port, GigE PoE Surge Prot, Rack Mt
Mfr # TP-ESP-1G-24RM
Zoro # G4583619
product price: $769.99
/ea
Free Shipping & Returns
$769.99
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Mounting Style Rack
- Peak Pulse Current 100A (10/1000us, 300 times with 3mins interval)
- Operating temperature -40 to +85°C (-40 to +185°F)
- PoE Operating Current 2.5A Max
- Enhanced ESD Protection +/-15KV (air), +/- 8KV (contact), Class C
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Tycon Systems
- MFR # TP-ESP-1G-24RM
- Zoro # G4583619
- UPC # 810017121731
- Country of Origin Taiwan, Province of China
- Category Surge Protectors
Dimensions
Body Size (L x W x H) | 432 x 114 x 44.5mm (17" x 4.5" x 1.75") |
Details
Item | Surge Protector |
Mounting Style | Rack |
Peak Pulse Current | 100A (10/1000us, 300 times with 3mins interval) |
Operating temperature | -40 to +85°C (-40 to +185°F) |
PoE Operating Current | 2.5A Max |
Enhanced ESD Protection | +/-15KV (air), +/- 8KV (contact), Class C |
Impulse Protected Voltage | <650V |
Operating Humidity | 0% to 95% non condensing |
Rackmount Standard | 19" 1U |
Operating Voltage | Data 5V, PoE < 56V |
Max Surge Discharge Current | 10KA (8/20us, 10 times with 3 mins interval) |
Storage temperature | -40 to +85°C (-40 to +185°F) |
Grounding Stud - Threaded | 4mm |
Connectors | RJ45 Shielded Jacks |
Ethernet Cable Compatibility | CAT5, CAT5e, CAT6, CAT6a |
Response Time | <5ns |
Clamping Voltage | Data 10V, POE 120V (All 8 Pins) |
Insulation Resistance | >1,000 MOhm |
Shunt Capacitance | <25 pF |
Protection Mode | Differential & Common Mode |
Data Rate | 10/100/1,000 Mbps (1Gbps) |
Description
Network Lightning/Surge Protector, 24 Port Rack Mount, 1Gbps Data Rate, LAN/POE 70V Clamp Voltage, 10KA Surge
