Shop All Power Relays
Te Connectivity
V23079A1001B301
Mfr # 1393788-3
Zoro # G901033708
Sold in multiples of 50 for $157.50
$157.50
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Power Consumption - Relay 140 mW
- Electrical Connection - Power Relay Through Hole
- Features Bifurcated/Twin Contacts
- Number of Poles 2
- Body Width - Relay 0.283 in
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
Product Information
- Brand Te Connectivity
- MFR # 1393788-3
- Zoro # G901033708
- Country of Origin Mexico
- Category Power Relays
Dimensions
Body Width - Relay | 0.283 in |
Body Height - Relay | 0.386 in |
Body Depth - Relay | 0.571 in |
Details
Item - Relay | P2 V23079 Relay |
Power Consumption - Relay | 140 mW |
Electrical Connection - Power Relay | Through Hole |
Features | Bifurcated/Twin Contacts |
Number of Poles | 2 |
Contact Limiting Breaking Current | 2A |
Contact Limiting Short-Time Current | 2A |
Operating Temp. Range | -40 to 85°C |
Dielectric Voltage | 1000 Vrms Adjacent Contacts; 1500 Vrms Coil and Contact; 1000 Vrms Open Contacts |
Protection Category | RTIII |
Coil Resistance | 178 Ω |
Contact Voltage Rating | 220 VDC, 250 VAC |
Switching Voltage | 250 VAC, 220 VDC |
Contact Limiting Continuous Current | 2A |
Insulation Creepage | .098 in |
Coil Type | Monostable, DC, Polarized |
Contact Limiting Making Current | 2A |
Switching Current | 10mA @ .2V |
Insulation Clearance | .051 in |
