Shop All Lighting Contactors
Square D
Contactor, Type S, multipole lighting, mechanically held, 100A, 3 pole, 110/120VAC 50/60Hz coil, open style
Mfr # 8903SQO11V02
Zoro # G0568298
product price: $1,724.99
/ea
Free Shipping & Returns
$1,724.99
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Type S
- Number of Poles 3
- Coil Volts 600VAC
- Enclosure NEMA Rating Not rated
- Full Load Amps 100
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Square D
- MFR # 8903SQO11V02
- Zoro # G0568298
- UPC # 785901102427
- Country of Origin Mexico
- Category Lighting Contactors
Dimensions
Height | 184 mm |
Width | 151 mm |
Depth | 171 mm |
Details
Item | Lighting Contactor |
Type | S |
Number of Poles | 3 |
Coil Volts | 600VAC |
Enclosure NEMA Rating | Not rated |
Full Load Amps | 100 |
Hz | 60/50 Hz |
Standards | UL Listed; CSA |
Pilot Light | No |
Current Rating | 100 A |
Control Type | No control units |
Electrical Connections | Lugs |
Enclosure Type | Not rated (open device) surface none |
Auxiliary Contacts | Without |
Control Circuit Voltage | 120 V AC 60 Hz; 110 V AC 50 Hz |
[Uc] Control Circuit Voltage | 120 V AC 60 Hz, 110 V AC 50 Hz |
Product or Component Type | Mechanically Held Lighting Contactor |
Local Signalling | without pilot light |
Poles Description | 3P |
Description
8903S lighting contactors are for lighting control applications. 8903S lighting contactors are available in either mechanically held or electrically held versions. This is a mechanically held device. This contactor is designed to switch 100 amperes. This device 2 pole device has 2 NO contacts. Supplied with a 110/120 VAC 50/60 Hz interchangeable operating coil but other coils are available in a wide variety of common voltages up to 600VAC. Contactor is an open device. A variety of enclosure types are available. Coils and contacts are easily replaced. Lighting contactor is 7.26 inches tall, 5.94 inches wide and 6.72 inches deep. 8903L lighting contactors are UL Listed and CSA Certified.
