Shop All Programmable Logic Controllers
Siemens

Module

product price: $13,167.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Height 708 millimetre
  • Width 305 millimetre
  • Depth 357 millimetre
  • description of product type PM240-2
  • Brake chopper integrated Yes
See all product information
Get 10% Off Your First Order
Real Support From Real People Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
visa mastercard american express discover paypal
Net 30

Product Information

Dimensions

Height 708 millimetre
Width 305 millimetre
Depth 357 millimetre

Details

description of product type PM240-2
Brake chopper integrated Yes
Output phases, number of 3
Protection type IP IP20
max. output power with linear load and rated output voltage 110 kilowatt
Design of frequency changer U converter
Rated output current 250 ampere
Rated output voltage 400 volt
Max. output frequency 550 hertz
max. mains voltage 480 volt
max. output power with square load at rated output voltage 132 kilowatt
Relative symmetric mains frequency tolerance 5 percent
Use in the industrial area permissible No
Relative symmetric mains voltage tolerance 10 percent
Input phase number 3
Min. network voltage 380 volt
Power loss, static, current-independent [Pls] 48.1 watt

Description

SINAMICS G120 POWER PM240-2 WITHOUT FILTER WITH BUILT IN BRAKING CHOPPER 3AC380-480V +10/-20% 47-63HZ OUTPUT HIGH OVERLOAD: 110KW FOR 200% 3S,150% 57S,100% 240S AMBIENT TEMP -20 TO +50 DEG C HO OUTPUT LOW OVERLOAD: 132kW FOR 150% 3S,110% 57S,100% 240S AMBIENT TEMP -20 TO +40 DEG C LO 708 X 305 X 357 HXWXD, FSF PROTECTION IP20 WITHOUT CONTROL UNIT AND PANEL APPROVED FOR CU FIRMWARE- VERSION V4.7 HF8
