Single function relay, Harmony Timer Relays, 5A, 2CO, 0.1s..100h, on delay, 120V AC

Mfr # REXL2TMF7
Zoro # G5956725

$59.75

Free Shipping on orders over $50

after you

Free 30-Day Returns

Key Features

Function - Timing Relay power on-delay
Mounting - Relay plug-in socket)
Contact Form - Relay 2 C/O
Min. Time Setting - Timer 10...100 h || 6...60 s || 6...60 min || 1...10 min || 0.1...1 s || 1...10 s || 1...10 h
Power Consumption - Relay 2.6 VA

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Schneider Electric
MFR # REXL2TMF7
Zoro # G5956725
Country of Origin Indonesia
Category Time Delay Relays

Dimensions

Width

21 mm

Details

Item - Relay	single function relay
Function - Timing Relay	power on-delay
Mounting - Relay	plug-in socket)
Contact Form - Relay	2 C/O
Min. Time Setting - Timer	10...100 h \|\| 6...60 s \|\| 6...60 min \|\| 1...10 min \|\| 0.1...1 s \|\| 1...10 s \|\| 1...10 h
Power Consumption - Relay	2.6 VA
Standards	cULus\|\| CSA
Item	Timer,250VAC,5A,Rexl +options
Type of Output	relay
Input or Control Voltage Range	0.85...1.15 Us
Number of Functions	1
Contact Material	cadmium free
Hz - Electrical	50/60 Hz
Setting Accuracy of Time Delay	10 % at full scale 25°C IEC 61812-1
Repeat Accuracy	+/- 0.5 %
Relative Humidity	95-95 % without condensation IEC 60068-2-6
Ambient Air Temperature For Operation	-20-60°C
Line Rated Current	5 A AC
Vibration Resistance	0.35 mm 10-55 Hz)IEC 60068-2-6
Dielectric Strength	2 kV 1 mA/1 minute 50 Hz IEC 60601-1, 2 kV 1 mA/1 minute 50 Hz IEC 61812-1
Maximum Switching Capacity	4 x 5 A
Resistance To Electrostatic Discharge	6 kV in contact IEC 61000-4-2 level 3, 8 kV in air IEC 61000-4-2 level 3
Resistance To Electromagnetic Fields	10 V/m IEC 61000-4-3 level 3
Minimum Switching Current	100 mA
Fixing Mode	plug-in (socket)
Temperature Drift	0.05 %/°C
Component Name	REXL
[Us] Rated Supply Voltage	120 V AC 50/60 Hz
Surge Withstand	2 kV IEC 61000-4-5 level 3
Creepage Distance	4 kV/3 IEC 60664-1
Range of Product	Harmony Timer Relays
Voltage Drift	+/- 0.2 %/V
Mechanical Durability	10000000 cycles
Local Signalling	for output in operation 1 LED (red), for power ON 1 LED (yellow)
[Ui] Rated Insulation Voltage	250 V IEC 255 Group C, 250 V VDE 0010
Immunity To Voltage Dips	>= 95 % / 1 s IEC 61000-4-11, 30 % / 10 ms IEC 61000-4-11, 60 % / 100 ms IEC 61000-4-11
Resistance To Fast Transients	2 kV IEC 61000-4-4 level 3
Reset Time	250 ms after time delay, on de-energisation, 50 ms during time delay, on de-energisation
Ambient Air Temperature For Storage	-40-70°C
Electrical Durability	100000 cycles 250 V AC resistive
Ip Degree of Protection	IP50 conforming to IEC 60529
Immunity To Microbreaks	5 ms
Immunity To Radioelectric Fields	10 V 0.15...80 MHz)IEC 61000-4-6 level 3
Output Overvoltage Protection	2 J
Temporary Permissible Current	10 A < 10 s
Disturbance Radiated/Conducted	class B EN 55022 (EN 55011 group 1)

Description

Timer,250VAC,5A,Rexl +options
