Interface plug-in relay, 6 A, 1 CO, with, 12V AC/DC Coil Volts, 1 C/O

Mfr # RSL1PRJU
Zoro # G600905238

$16.65

Sold in multiples of 10 for $166.50

Free Shipping on orders over $50

Free 30-Day Returns

Key Features

Coil Volts 12V AC/DC
AC Contact Rating - Relay 6A @ 250V AC
Contact Form - Relay 1 C/O
Mounting - Relay 35 mm symmetrical DIN rail
Power Consumption - Relay 0.17 W

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Schneider Electric
MFR # RSL1PRJU
Zoro # G600905238
Country of Origin China
Category Plug-In Relays

Dimensions

Body Height - Relay	78.6 mm
Body Width - Relay	6.2 mm
Body Depth - Relay	101 mm

Details

Item	Interface plug-in relay,6 A,1 CO,with
Coil Volts	12V AC/DC
AC Contact Rating - Relay	6A @ 250V AC
Contact Form - Relay	1 C/O
Mounting - Relay	35 mm symmetrical DIN rail
Power Consumption - Relay	0.17 W
Contact Material	Silver Alloy (AgSnO2)
Features	Status LED
Standards	CSA C22.2 No 14; UL 508; EN/IEC 61810-1; CE; GOST
Dielectric Strength	1000 V AC between contacts; 4000 V AC between coil and contact
Switching Power	Max 1500 VA; 150 W; Min 120 mW
Switching Voltage	12/277V
Protection Category	RT III
Operating Temp. Range	-40-55°C
Operating Time	5 ms reset \|\| 12 ms
Current Rating	6 A 1 C/O AC-1/DC-1)IEC/UL
Series	RSL; interface relay
Coil Resistance	848 Ohm
Pin Shape	flat (PCB type)
Status Led	with
Drop-Out Voltage Threshold	>= 0.05 Uc
Terminals Description Iso N°1	(A1-A2)CO, (11-12-14)OC
Device Short Name	RSL
Average Coil Consumption	0.17 W, DC
Electrical Durability	60000 cycles resistive, 6 A 250 V, AC-1
Marking	CE
Minimum Switching Voltage	12 V
Vibration Resistance	10 gn +/- 1 mm 10-150 Hz)10 cycles not operating IEC 60068-2-6, 5 gn +/- 1 mm 10-150 Hz)10 cycles in operation IEC 60068-2-6
Product or Component Type	pre-assembled plug-in relay with socket
Contact Terminal Arrangement	separate
Maximum Switching Voltage	277 V
Ip Degree of Protection	IP40 conforming to IEC 60529
Test Levels	level A group mounting
Operating Rate	<= 72000 cycles/hour no-load, <= 360 cycles/hour under load
Mechanical Durability	10000000 cycles
Series Name	interface relay
Maximum Switching Capacity	1500 VA, 150 W
Average Resistance	848 Ohm DC 23°C +/- 10 %
Shock Resistance	10 gn 11 ms) in operation IEC 60068-2-27, 5 gn 11 ms) not operating IEC 60068-2-27
[Uc] Control Circuit Voltage	12 V AC/DC
Operating Position	any position
Clamping Force	10-40 N
Fixing Mode	plastic compression spring
[Uimp] Rated Impulse Withstand Voltage	6 kV IEC
Minimum Switching Current	100 mA
Load Current	6 A 250 V AC 0.5 mm mounting distance
Phenolic Free Solution	Yes
Range of Product	Harmony Electromechanical Relays
Connections - Terminals	spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) flexible with cable end, spring terminals, 1 x 0.2...1 x 1.5 mm² AWG 24...AWG 16) solid without cable end
Ambient Air Temperature For Operation	-40-55°C
Control Type	without push-button
[Ithe] Conventional Enclosed Thermal Current	6 A -40-55°C
Minimum Switching Capacity	120 mW
Device Presentation	complete product
Ambient Air Temperature For Storage	-40-85°C
[Ui] Rated Insulation Voltage	250 V IEC, 277 V cUL
Contact Operation	standard
Input Voltage	12 V AC/DC 11.4...14.4 V)
