Illuminated push-button head, Harmony 9001SK, plastic, plastic guard flush, red, 30mm, spring return, LED red, 120V

Mfr # 9001SK1L38LRR
Zoro # G3300434

$123.99

Free Shipping & Returns

Free Shipping on orders over $50

Free 30-Day Returns

Key Features

Bezel Material plastic
Standards EN/IEC 60947-1 || EN/IEC 60947-5-4 || UL 508 || EN/IEC 60947-5-1 || JIS C 4520 || JIS C 852 || CSA C22.2 No 14
Bulb Base BA 9s
Protective Treatment TC
Operating Position any position

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Schneider Electric
MFR # 9001SK1L38LRR
Zoro # G3300434
Country of Origin Mexico
Category Push Button Switches

Dimensions

Mounting Diameter

30 mm

Details

Item	PUSHBUTTON OPERATOR 30MM SK +OPTIONS
Bezel Material	plastic
Standards	EN/IEC 60947-1 \|\| EN/IEC 60947-5-4 \|\| UL 508 \|\| EN/IEC 60947-5-1 \|\| JIS C 4520 \|\| JIS C 852 \|\| CSA C22.2 No 14
Bulb Base	BA 9s
Protective Treatment	TC
Operating Position	any position
Light Source Colour	red
Device Presentation	basic element
[Icm] Rated Short-Circuit Making Capacity	12 kA 600 V AC-15, 7200 VA \|\| 15 kA 480 V AC-15, 7200 VA \|\| 30 kA 240 V AC-15, 7200 VA \|\| 60 kA 120 V AC-15, 7200 VA \|\| 0.27 kA 250 V DC-13 \|\| 0.55 kA 125 V DC-13 \|\| 0.1 kA 600 V DC-13
Short-Circuit Protection	10 A cartridge fuse EN/IEC 60947-5-1
Contacts Type And Composition	without contact block
Tightening Torque	0.8-0.8 N.m EN/IEC 60947-1
Shape Of Screw Head	cross slotted
Operator Additional Information	plastic guard
[Ui] Rated Insulation Voltage	250 V 3)EN/IEC 60947-1
Connections - Terminals	screw clamp terminals 1 x 0.22 to 2 x 1.5 mm² EN/IEC 60947-1
Shock Resistance	50 gn IEC 60068-2-27
Cap/Operator Or Lens Colour	red
Nema Degree Of Protection	NEMA 1 \|\| NEMA 12 \|\| NEMA 13 \|\| NEMA 2 \|\| NEMA 3 \|\| NEMA 3R \|\| NEMA 4 \|\| NEMA 4X
Light Source	Red LED
Ambient Air Temperature For Storage	-40-70°C
Type Of Operator	spring return
[Uimp] Rated Impulse Withstand Voltage	2.5 kV EN/IEC 60947-1
[Us] Rated Supply Voltage	120 V, 120 V AC/DC
Light Block Supply	direct 120 V AC/DC
Device Short Name	9001SK
Vibration Resistance	7 gn 2-500 Hz)IEC 60068-2-6
Positive Opening	without
Product Or Component Type	head for illuminated push-button
Ip Degree Of Protection	IP66 IEC 60529
Electrical Shock Protection Class	class II IEC 61140
Ambient Air Temperature For Operation	-25-70°C
Rated Breaking Capacity	1.2 kA 600 V AC-15, 720 VA \|\| 1.5 kA 480 V AC-15, 720 VA \|\| 3 kA 240 V AC-15, 720 VA \|\| 6 kA 120 V AC-15, 720 VA \|\| 0.27 kA 250 V DC-13 \|\| 0.55 kA 125 V DC-13 \|\| 0.1 kA 600 V DC-13
Mechanical Durability	5000000 cycles
[Ith] Conventional Free Air Thermal Current	10 A
Product Certifications	UL 508 \|\| NEMA
Operator Profile	flush, red flush, unmarked
Shape Of Signaling Unit Head	octagonal
[Ie] Rated Operational Current	0.55 A 125 V, DC-13, A600-Q600 NEMA
Range of Product	Harmony 9001SK
