Control Relay 600Vac 10Amp Iec +Options

Mfr # CA4KN22BW3
Zoro # G0847835

$63.85

Free Shipping on orders over $50

after you

Free 30-Day Returns

Key Features

Coil Volts 600VAC
Standards EN/IEC 60947-4-1 || GB/T 14048.4 || UL 60947-4-1 || CSA C22.2 No 60947-4-1 || JIS C8201-4-1
Protective Treatment TC IEC 60068
Product Or Component Type control relay
Mechanical Robustness vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6 || vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 || shocks contactor open10 Gn for 11 ms IEC 60068-2-27 || shocks contactor closed15 Gn for 11 ms IEC 60068-2-27

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Schneider Electric
MFR # CA4KN22BW3
Zoro # G0847835
UPC #
785901967293
Country of Origin France
Category Control Relays

Dimensions

Depth	57 mm
Width	45 mm
Height	58 mm

Details

Coil Volts	600VAC
Item	Control Relay 600Vac 10Amp Iec +Options
Standards	EN/IEC 60947-4-1 \|\| GB/T 14048.4 \|\| UL 60947-4-1 \|\| CSA C22.2 No 60947-4-1 \|\| JIS C8201-4-1
Protective Treatment	TC IEC 60068
Product Or Component Type	control relay
Mechanical Robustness	vibrations contactor open2 Gn, 5...300 Hz IEC 60068-2-6 \|\| vibrations contactor closed4 Gn, 5...300 Hz IEC 60068-2-6 \|\| shocks contactor open10 Gn for 11 ms IEC 60068-2-27 \|\| shocks contactor closed15 Gn for 11 ms IEC 60068-2-27
[Ith] Conventional Free Air Thermal Current	10 A 50Â°C
Operating Altitude	6561.68 ft (2000 m) without derating
Product Certifications	CB Scheme \|\| CCC \|\| UL \|\| CSA \|\| EAC \|\| CE \|\| UKCA
Insulation Resistance	> 10 MOhm
Connections - Terminals	screw clamp terminals 1 1.5-4 mmÂ²solid \|\| screw clamp terminals 2 1.5-4 mmÂ²solid \|\| screw clamp terminals 1 0.75-4 mmÂ²flexible with cable end \|\| screw clamp terminals 2 0.75-4 mmÂ²flexible without cable end \|\| screw clamp terminals 1 0.34-1.5 mmÂ²flexible with cable end \|\| screw clamp terminals 2 0.34-1.5 mmÂ²flexible without cable end
Operating Time	10...20 ms coil de-energisation and NO opening \|\| 15...25 ms coil de-energisation and NC closing \|\| 30...40 ms coil energisation and NO closing \|\| 25...35 ms coil energisation and NC opening
Irms Rated Making Capacity	110 A IEC 60947
Coil Technology	built-in bidirectional peak limiting diode suppressor
Ambient Air Temperature For Storage	-50-80Â°C
Contactor Application	control circuit
Range	TeSys
Control Circuit Voltage Limits	drop-out 0.1...0.75 Uc 50Â°C) \|\| operational 0.7...1.3 Uc 50Â°C)
Ip Degree Of Protection	IP2X
Mechanical Durability	30 Mcycles
Tightening Torque	1.3 N.m screw clamp terminals flat Ã˜ 6 mm \|\| 1.3 N.m screw clamp terminals Philips No 2 6 mm \|\| 1.3 N.m screw clamp terminals pozidriv No 2
Ambient Air Temperature For Operation	-25-50Â°C
Product Name	TeSys CAK
Minimum Switching Voltage	17 V
Utilisation Category	DC-13 \|\| AC-15
[Ui] Rated Insulation Voltage	690 V IEC 60947 \|\| 750 V VDE 0110 group C \|\| 690 V BS 5424 \|\| 600 V CSA C22.2 No 14
Minimum Switching Current	5 mA
[Uc] Control Circuit Voltage	24 V DC
Pole Contact Composition	2 NO + 2 NC
Associated Fuse Rating	10 A gG IEC 60947 \|\| 10 A gG VDE 0660
Flame Retardance	V1 conforming to UL 94 \|\| requirement 2 conforming to NF F 16-101 \|\| requirement 2 conforming to NF F 16-102
Non Overlap Distance	0.5 mm
Inrush Power In W	1.8-1.8 W 20Â°C)
Maximum Operating Rate	6000 cyc/h
Heat Dissipation	1.8-1.8 W
Mounting Support	rail \|\| plate
Control Circuit Type	DC low consumption
Immunity To Microbreaks	2 ms
Hold-In Power Consumption In W	1.8-1.8 W 20Â°C
Device Short Name	CA4K
[Ue] Rated Operational Voltage	<= 690 V <= 400 Hz
