Schneider Electric
Additional earthing block, TeSys Control, 80A, for V3 / V4
Mfr # VZ15
Zoro # G0558428
product price: $53.15
/ea
$53.15
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Height 83 mm
- Depth 46 mm
- Standards IEC 60947-3
- Width 20 mm
- Mechanical Robustness vibrations 10 to 150 Hz 5 gn) IEC 60068-2-6 || shocks 11 ms 15 gn) IEC 60068-2-27
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Schneider Electric
- MFR # VZ15
- Zoro # G0558428
- UPC # 785901613572
- Country of Origin Czechia
- Category Door Switches
Dimensions
Height | 83 mm |
Depth | 46 mm |
Width | 20 mm |
Details
Item | Grounding Module |
Standards | IEC 60947-3 |
Mechanical Robustness | vibrations 10 to 150 Hz 5 gn) IEC 60068-2-6 || shocks 11 ms 15 gn) IEC 60068-2-27 |
Network Type | DC || AC |
[Ith] Conventional Free Air Thermal Current | 80 A |
Network Frequency | 50/60 Hz |
Ip Degree Of Protection | IP20 conforming to IEC 60529 |
Range | TeSys |
Protective Treatment | TC |
[Uimp] Rated Impulse Withstand Voltage | 6 kV |
Product Certifications | UL || CSA || GL || UKCA |
Device Short Name | VZ |
Mounting Location | left || right |
Ambient Air Temperature For Operation | -20-50°C |
Product Compatibility | V3 || V4 |
Contacts Type And Composition | without |
[Ue] Rated Operational Voltage | 690 V AC 50/60 Hz |
Fire Resistance | 960°C IEC 60695-2-1 |
Connections - Terminals | screw clamp terminals |
Product Or Component Type | additional earthing block |
Performance Level | high performance |
Description
VZ15 is an add-on earthing module for TeSys Vario switch-disconnector from Schneider Electric. Rated 63A to 80A 690V, to be used with V3 and V4 switch bodies. Available worldwide, multi-standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHs/Reach). Multi standards certified (IEC, UL, CSA, CCC, EAC), Green Premium compliant (RoHS/REACh).
