  13. Trolley, 2000 lb. Load Cap., Push Trolley
Shop All Trolleys
Saginaw Products

Trolley, 2000 lb. Load Cap., Push Trolley

product price: $260.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Load Capacity 2,000 lb
  • Fits Beam Flange W 3 in to 8 in
  • Fits Beam Height 5 in to 24-1/64 in
  • Min. Radius Curve 48 in
  • Trolley Wheel Dia. 2 3/4 in
See all product information
Get 10% Off Your First Order
Real Support From Real People Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
visa mastercard american express discover paypal
Net 30

Product Information

Dimensions

Fits Beam Height 5 in to 24-1/64 in
Min. Radius Curve 48 in
Trolley Wheel Dia. 2 3/4 in
Manufacturers Warranty Length 1 yr
Trolley Wheel Diameter 2 4/5 in
For Max. Beam Flange Width 8 in
Mfr. Warranty Length 1 yr
For Maximum Beam Height 24 1/32 in
For Min. Beam Flange Width 3 in
Minimum Radius Curve 48 in
For Minimum Beam Height 5 in

Details

Trolley Item Push Trolley
Load Capacity 2,000 lb
Fits Beam Flange W 3 in to 8 in
Standards ISO 9001: 2015
Item Trolley
Wheel Material Solid Cast Iron
Head Room To Bail 6 3/16 in
Head Room To Shaft 2 1/4 in
Maximum Load Capacity 2,000 lb
Headroom to Mounting Point 6 3/16 in
Trolley Wheel Material Cast Iron
Trolley Type Push
Headroom to Connecting Shaft 2 1/4 in

Description

Trolley, Trolley Type Push, Maximum Load Capacity 2,000 lb, For Minimum Beam Flange Width 3 in, For Maximum Beam Flange Width 8 in, Headroom to Connecting Shaft 2 1/4 in, Headroom to Mounting Point 6 3/16 in, For Minimum Beam Height 5 in, For Maximum Beam Height 24 1/32 in, Minimum Radius Curve 48 in, Trolley Wheel Diameter 2 4/5 in, Trolley Wheel Material Cast Iron, Manufacturer's Warranty Length 1 yr, Standards ISO 9001: 2015
