Shop All Strain Relief Connector
Raychem
TXR41AB45-1006BI
Mfr # TXR41AB45-1006BI
Zoro # G800963052
product price: $198.99
/ea
Sold in multiples of 25 for $4,974.75
Free Shipping & Returns
$4,974.75
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Color Olive Drab
- Termination Device Included TR06BI
- Adapter Entry Size 6
- Pluggable I/O Accessory Type Tinel-Lock Adapter
- Backshell Material Aluminum
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
Product Information
- Brand Raychem
- MFR # TXR41AB45-1006BI
- Zoro # G800963052
- Country of Origin United Kingdom
- Category Strain Relief Connector
Dimensions
| Adapter Entry Size | 6 |
| Cable Diameter Range | 4.8 “ 7.6 mm[.188 “ .3 in] |
| Cable Entry Diameter | .2 “ 9.5 mm[.01 “ .38 in] |
| Connector Shell Size | 10,11 |
Details
| Color | Olive Drab |
| Termination Device Included | TR06BI |
| Pluggable I/O Accessory Type | Tinel-Lock Adapter |
| Backshell Material | Aluminum |
| Connector Detail Specification Number | MS24266, MS27467, MS27468, MS27472, MS27473, MS27474, MS27479, MS27480, MS27481, MS27484, MS27497, MS27652, MS27653, MS27656, MS27661, MS27665 |
| Adapter Plating Material | Cadmium (AMS-QQ-P-416, Type II, Class 3) |
| Salt Spray Resistance | 500 Hr |
| Termination Device Type | Side-Entry Tinel-Lock Ring,Tinel-Lock Adapter,Tinel-Lock Ring |
| TE Adapter Code | 41 |
| Adapter Angle | 45 |
| Connector General Specification Number | MIL-DTL-38999 Series I,MIL-DTL-38999 Series I/Class E,P,T,MIL-DTL-38999 Series I/Class E,T,MIL-DTL-38999 Series II/Class E,P,T,MIL-DTL-38999 Series II/Class E,T,MIL-DTL-38999 Series II/Class T |
| Overbraid Termination | Tinel-Lock Ring |
| Series | Raychem TXR |
| Operating Temperature Range | -65 “ 175 °C[-85 “ 347 °F] |
