Professional Plastics

Gray PET Ertalyte TX Rod (Q), 0.625 Dia [Ft]


product price: $38.39
/ea

Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Weight 1
  • Color Gray
  • Height 0.625
  • Width 0.625
  • Material Ertalyte
See all product information
Get 10% Off Your First Order
Real Support From Real People Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
visa mastercard american express discover paypal
Net 30

Product Information

Dimensions

Height 0.625
Width 0.625
Length 12

Details

Weight 1
Color Gray
Material Ertalyte
CoLT Expansion (x 10-5 in./in./Deg:F) 4.5
FDA Compliant Yes
3A Dairy Compliant Yes
Tensile Strength (psi @ 73 Deg;) 10500
UL94 Flammability Rating Method: UL 94 H-B
Heat Deflection Temp. (264 psi) Deg:F 180
Tensile Elongation at Break (% @ 73 Deg: F) 5
Specific Gravity (73 Deg: g/cm3) 1.44
Thermal Conductivity (BTU-in/ft²-hr-°F) 1.9
Max. Recommended Use Temp (Deg:F) 210
Flexural Strength (psi @ 73 Deg: F) 14000
USDA Compliant Yes

Description

Ertalyte® TX for machining high-wear-resistant parts is an unreinforced semi-crystalline thermoplastic polyester (PET-P) that has a solid lubricant filler. The material has excellent performance in both high-pressure and high-velocity conditions, and is ideally suited for applications involving soft metal and plastic mating surfaces. Key properties of Ertalyte TX, are its high strength and stiffness, high wear-resistance, very good dimensional stability, high creep resistance and very good chemical resistance. This combination of properties make it an ideal material for machining bushings and bearings that require no startup or running lubrication. Ertalyte TX has FDA and USDA compliance and is ideal for applications in food packaging and processing equipment. Ertalyte TX shapes offer dimensional stability, wear resistance, and low-friction characteristics superior to those properties of competitive filled polyethylene terephthalate polymers. Excellent replacement for full-strength Delrin® AF, when parts require food contact. Standard Sheet Size: 24" x 39.4" Standard Rods: 10 Foot (may be cut in-half for FedEx or UPS Shipping to save freight) - add Shipping Note at Check-Out or Call for Assistance

Restrictions
