Piab
Vacuum Generator, 14.5 mm Overall H
Mfr # 01.22.882
Zoro # G410064743
product price: $57.39
/ea
$57.39
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Weight 0.35 oz
- Overall Width 70 mm
- Overall Height 14.5 mm
- Vacuum Port Gender Female
- Maximum Supply Pressure 101.5 psi
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
Product Information
- Brand Piab
- MFR # 01.22.882
- Zoro # G410064743
- Country of Origin Singapore
- Category Vacuum Pump Parts
Dimensions
| Overall Width | 70 mm |
| Overall Height | 14.5 mm |
| Pressure Port Size | 6 mm |
| Overall Depth | 14.5 mm |
| Vacuum Port Size | 6 mm |
Details
| Item | Vacuum Generator |
| Weight | 0.35 oz |
| Vacuum Port Gender | Female |
| Maximum Supply Pressure | 101.5 psi |
| Vacuum Port Type | Tube |
| Standards | RoHS Compliant |
| Pressure Port Gender | Female |
| Maximum Operating Temperature | 176 Degrees F |
| Maximum Flow Rate | 0.59 scfm |
| Series | piINLINE MICRO |
| Air Consumption | 0.25 scfm |
| Minimum Operating Temperature | 14 Degrees F |
| Cartridge Type | COAX MICRO Si |
| Minimum Flow Rate | 0 scfm |
| Maximum Vacuum Pressure | 22.15 in Hg |
| Pressure Port Type | Tube |
Description
Item Vacuum Generator, Air Consumption 0.25 scfm, Cartridge Type COAX MICRO Si, Maximum Flow Rate 0.59 scfm, Maximum Operating Temperature 176 Degrees F, Maximum Supply Pressure 101.5 psi, Maximum Vacuum Pressure 22.15 in Hg, Minimum Flow Rate 0 scfm, Minimum Operating Temperature 14 Degrees F, Overall Depth 14.5 mm, Overall Height 14.5 mm, Overall Width 70 mm, Pressure Port Gender Female, Pressure Port Size 6 mm, Pressure Port Type Tube, Series piINLINE MICRO, Standards RoHS Compliant
