  9. Pressure Transmitter, 0 psig to 6000 psig, 0.25% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, 1/2 NPT Conduit w/ 6 ft Cable Attached
Shop All Transmitters
Noshok

Pressure Transmitter, 0 psig to 6000 psig, 0.25% Accuracy (BFSL), 4 mA to 20 mA Output, 1/4 NPT Male, 1/2 NPT Conduit w/ 6 ft Cable Attached

product price: $702.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
after you
Free 30-Day Returns

Key Features

  • Wetted Materials - Transmitters 316 Stainless Steel
  • Electrical Connections - Transmitter 1/2" NPT Male Conduit with 6 ft Integral Cable
  • Power Required - Transmitters 10 to 30V DC
  • Standards European Conformity (CE) Compliant to Electromagnetic Compatibility (EMC) Norm European Standards (EN) 61326:2014/A1:1998, Radio Frequency Interference (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) Protection
  • Material of Construction 316 Stainless Steel
See all product information
Get 10% Off Your First Order
Real Support From Real People Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
visa mastercard american express discover paypal
Net 30

Product Information

Dimensions

Connection Size 1/4 in

Details

Item Pressure Transmitter
Wetted Materials - Transmitters 316 Stainless Steel
Electrical Connections - Transmitter 1/2" NPT Male Conduit with 6 ft Integral Cable
Power Required - Transmitters 10 to 30V DC
Standards European Conformity (CE) Compliant to Electromagnetic Compatibility (EMC) Norm European Standards (EN) 61326:2014/A1:1998, Radio Frequency Interference (RFI), Electromagnetic Interference (EMI) and Electrostatic Discharge (ESD) Protection
Material of Construction 316 Stainless Steel
Temp. Range -22 to 176°F
Pressure Range 0 to 6000 psig
Application Chemical Processing, Gas Pressure Measurement, Oil Field & Offshore, Mining, Well Head Measurement
Connection MNPT
Output 4 to 20 mA
Operating Temp. -22 to 212°F
Measuring Element 316 Stainless Steel
Environmental Rating IP65 to IP67
Response Time Less Than or Equal 1 ms
Service Life Greater Than 100,000,000 Load Cycles
Max. Operating Temperature 100°C
Vibration 20G
Electrical Protection Reverse Polarity, Over-Voltage and Short Circuit Protection
Min. Operating Temperature -300°C
Shock 1000G
Compensated Temperature Range 32 to 176°F
Media Temperature Range -40 to 212°F

Description

Pressure Transmitter, 0 psig to 30 psig, 0.25% Accuracy BFSL, 4 mA to 20 mA Output, 1/4 NPT Male, 1/2 NPT Conduit w/ 6 ft Cable Attached. Current and voltage outputs available. 316 stainless Steel and Elgiloy wetted parts. Factory Mutual and Canadian Standards Association approved. CE compliant to suppress RFI, EMI and ESD. NACE MR0175/ISO 15156 compliant. NSI/ISA-12.27.01 approved single seal.
