Shop All Air Amplifiers
Nex Flow
Air Amplifier
Mfr # 40002
Zoro # G011471216
product price: $236.99
/ea
Free Shipping & Returns
$236.99
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Amplification Ratio 16
- Discharge Dia. 2 in
- Overall Length 3 1/4 in
- System of Measurement Inch
- Flow Pattern Width at 6 Inches 2 3/8 in
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Nex Flow
- MFR # 40002
- Zoro # G011471216
- UPC # 849169000519
- Country of Origin Canada
- Category Air Amplifiers
Dimensions
Discharge Dia. | 2 in |
Overall Length | 3 1/4 in |
Flow Pattern Width at 6 Inches | 2 3/8 in |
Inlet Size | 3/8 in |
Flow Pattern Width at 18 Inches | 6 in |
Inlet Diameter | 3 in |
Overall Width | 3 in |
Flow Pattern Width at 12 Inches | 4 3/16 in |
Overall Height | 3 in |
Details
Item | Air Amplifier |
Amplification Ratio | 16 |
System of Measurement | Inch |
Air Inlet Type | NPT |
Minimum Operating Pressure | 20 psi |
Body Material | Aluminum |
Air Output Volume @ 80 psi | 344 scfm |
Maximum Operating Pressure | 120 psi |
Air Consumption | 26 scfm |
Maximum Sound Level | 82 dBA |
Body Material Finish | Anodized |
Product Type | Air Amplifier Only |
For Fluid Type | Compressed Air |
Output Type | Adjustable |
Description
Air Amplifier, Amplification Ratio 16, Inlet Size 3/8 in, Air Inlet Type NPT, Inlet Diameter 3 in, Discharge Dia. 2 in, Maximum Sound Level 82 dBA, Body Material Aluminum, Air Consumption 26 scfm, Air Output Volume @ 80 psi 344 scfm, Output Type Adjustable, Includes Filter Separator Not Applicable, Includes Pressure Regulator Not Applicable, Includes Shims Not Applicable, Body Material Finish Anodized, System of Measurement Inch, Overall Length 3 1/4 in, Maximum Operating Pressure 120 psi
