Active Ethernet I/O Server, 6Rtd/4Do

Mfr # ioLogik E2260
Zoro # G4578326

$659.99

Free Shipping & Returns

Free Shipping on orders over $50

Free 30-Day Returns

Key Features

Mounting DIN rail or wall
Digital Outputs 4 channels
Input connection 2 or 3 wire
Dimensions 115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)
Type Sink

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Moxa
MFR # ioLogik E2260
Zoro # G4578326
Country of Origin Taiwan, Province of China
Category Programmable Logic Controllers

Dimensions

115 x 79 x 45.6 mm (4.53 x 3.11 x 1.80 in)

Details

Mounting	DIN rail or wall
Digital Outputs	4 channels
Input connection	2 or 3 wire
Type	Sink
Accuracy	±0.1% FSR @ 25°C; ±0.3% FSR @ -10 and 60°C; ±0.5% FSR @ -40 and 75°C
Ambient Relative Humidity	5 to 95% (non-condensing)
Serial Line Protection	15 kV ESD for all signals
Sampling Rate	12 samples/sec (all channels)
Vibration	IEC 60068-2-6
Input Type	PT50, PT100, PT200, PT500, PT1000; JPT100, JPT200, JPT500, JPT1000; NI100, NI120, NI200, NI500, NI1000; Resistance of 310, 620, 1250, and 2200 ohms
Protocol	Modbus/RTU
I/O Mode	DO or Pulse Output
Protocols	Modbus/TCP, TCP/IP, UDP, DHCP, BOOTP, SNMP, HTTP, CGI, SNTP, SMTP
Safety	UL 508
Over-current Protection	2.6 A (4 channels @ 650 mA)
Protection	1.5 kV magnetic isolation
Input Impedance	625k ohms
Freefall	IEC 60068-2-32
Shock	IEC 60068-2-27
Power Input	24 VDC nominal, 12 to 36 VDC
RTD Inputs	6 channels
Over-temperature Shutdown	175°C
EMS	EN 61000-4-2, EN 61000-4-3, EN 61000-4-4; EN 61000-4-5, EN 61000-4-6, EN 61000-4-8; EN 61000-4-11, EN 61000-6-2
Operating temperature	Standard Models: -10 to 60°C (14 to 140°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F)
Isolation	3k VDC or 2k Vrms
Data Bits	8
Time	327,282 hrs
Altitude	Up to 2000 m
Interface	RS-485-2w: Data+, Data-, GND (3-contact terminal block)
Resolution	0.1°C or 0.1 ohm
Current Rating	200 mA per channel
Storage temperature	-40 to 85°C (-40 to 185°F)
Baudrate	1200 to 115200 bps
Database	Telcordia (Bellcore)
Stop Bits	1
Parity	None
Pulse Output Frequency	100 Hz
Over-voltage Protection	45 VDC
Wiring	I/O cable max. 14 AWG
Power Consumption	95 mA @ 24 VDC
Ethernet	1 10/100 Mbps RJ45 port
EMI	EN 61000-3-2; EN 61000-3-3; EN 61000-6-4; FCC Part 15, Subpart B, Class A

Description

Active Ethernet I/O Server, 6RTD/4DO

Restrictions

WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
