16Port Terminal Server, Dual 10/100M Eth., Rs-232, Rj-45 8Pin, Cn2610-16

Mfr # CN2610-16
Zoro # G4573076

$2,143.99

Free Shipping & Returns

Free Shipping on orders over $50

Free 30-Day Returns

Key Features

Operating temperature Standard Models: 0 to 55°C (32 to 131°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F); High Voltage Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Windows Real COM Drivers Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1 (x86/x64), Windows 2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded
Altitude Up to 2000 m
Freefall IEC-68-2-34, IEC-68-2-32
Stop Bits 1, 1.5, 2

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Moxa
MFR # CN2610-16
Zoro # G4573076
Country of Origin Taiwan, Province of China
Category Terminal Servers

Dimensions

Without ears: 440 x 198 x 45.5 mm (17.32 x 7.80 x 1.77 in); With ears: 480 x 198 x 45.5 mm (18.9 x 7.80 x 1.77 in)

Details

Operating temperature	Standard Models: 0 to 55°C (32 to 131°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F); High Voltage Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Windows Real COM Drivers	Windows 95/98/ME/NT/2000, Windows XP/2003/Vista/2008/7/8/8.1 (x86/x64), Windows 2008 R2/2012/2012 R2 (x64), Windows Embedded CE 5.0/6.0, Windows XP Embedded
Altitude	Up to 2000 m
Freefall	IEC-68-2-34, IEC-68-2-32
Stop Bits	1, 1.5, 2
EMS	EN 61000-4-2 ESD: contact 4 kV; air 8 kV; EN 61000-4-3 RS: 3 V/m (80 MHz to 1 GHz); EN 61000-4-4 EFT: Power 4 kV; Signal 2 kV; EN 61000-4-5 Surge: AC 1 kV (AC models); DC 2 kV (HV models); Signal 1 kV; EN 61000-4-6 CS: 3 V; EN 61000-4-8; EN 61000-4-11: AC m
Safety	UL 60950-1, EN 60950-1
Terminal Sessions	8 sessions per port
Baudrate	50 bps to 921.6 kbps
EMI	EN 55022 Class A, FCC part 15 Subpart B Class A
Storage temperature	Standard Models: -40 to 75°C (-40 to 167°F); Wide Temp. Models: -40 to 75°C (-40 to 167°F); High Voltage Wide Temp. Models: -40 to 85°C (-40 to 185°F)
Automatic Reboot Trigger	Built-in WDT (watchdog timer)
Data Bits	5, 6, 7, 8
EMC	55022/24
MTBF (mean time between failures)	CN2650I AC models: 99,320 hrs; CN2650I-8-HV-T: 191,326 hrs; CN2650I-16-HV-T: 116,924 hrs
Power Line Protection	1 kV burst (EN 61000-4-4: EFT/B), 2 kV surge (EN 61000-4-5)
RS-232	TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
Input Voltage	AC Models: 100 to 240 VAC, 47 to 63 Hz; DC Models: 110 VDC (88 to 300 VDC)
Configuration Options	Web Console, Serial Console, Telnet Console, Windows Search Utility
Fixed TTY Drivers	SCO Unix, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS X
Standard	Real COM, TCP Server, TCP Client, UDP, RFC2217, Terminal, Reverse Telnet, PPP, DRDAS, Redundant COM, Disabled
Network Protocols	ICMP, IPv4, TCP, UDP, DHCP, BOOTP, Telnet, DNS, SNMP, HTTP, SMTP, ARP, PPPoE, DDNS
RS-422	Tx+, Tx-, Rx+, Rx-, GND
Pull High/Low Resistor for RS-485	1 kΩ, 150 kΩ
Linux Real TTY Drivers	Linux 2.4.x, 2.6.x, 3.x
Connector	CN2610/2650: 8-pin RJ45; CN2650I: DB9 male, 8-pin RJ45
Speed	10/100 Mbps, auto MDI/MDIX
Serial Standards	CN2610: RS-232; CN2650/2650I: RS-232/422/485
Vibration	IEC-68-2-6
Ambient Relative Humidity	5 to 95% (non-condensing)
Number of Ports	8 or 16, 2 (2 IPs)
Flow Control	RTS/CTS, DTR/DSR, XON/XOFF
Terminator for RS-485	120 Ω
Housing	Metal
RS-485-4w	Tx+, Tx-, Rx+, Rx-, GND
Console Port	Dedicated RS-232 console port on rear panel (8-pin RJ45)
Parity	None, Even, Odd, Space, Mark
RS-485-2w	Data+, Data-, GND
Security Protocols	RADIUS, HTTPS, SSH, PAP, CHAP
Management	SNMP MIB-II
Magnetic Isolation	1.5 kV built-in
Serial Line Protection	2 kV optical isolation (CN2650I)
RS-485 Data Direction Control	ADDC® (Automatic Data Direction Control)
Power Consumption	CN2650 AC models: 235 mA @ 100 VAC, 145 mA @ 240 VAC; CN2650I HV models: 152 mA @ 88 VDC, 86 mA @ 300 VDC
IP Routing	Static, RIP-I, RIP-II
Alert Tools	Built-in buzzer and RTC (real-time clock)

Description

16 port Terminal Server, dual 10/100M Ethernet, RS-232, RJ-45 8pin, 100V or 240V
