Shop All Communication Cables
Molex
Rectangular Cable Assemblies Mini-Lock Cbl 2.5Mm P F-F 100Mm 5Ckts
Mfr # 151370501
Zoro # G005925725
product price: $4.89
/ea
Sold in multiples of 20 for $97.80
$97.80
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Series 15137
- Application Signal, Wire-to-Board
- Type Discrete Wire Assembly
- Cable Length 100.00mm
- Material - Resin Polyester
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Molex
- MFR # 151370501
- Zoro # G005925725
- Country of Origin India
- Category Communication Cables
Dimensions
Cable Length | 100.00mm |
Wire Size AWG | 22 |
Details
Series | 15137 |
Application | Signal, Wire-to-Board |
Type | Discrete Wire Assembly |
Material - Resin | Polyester |
Material - Plating Termination | Matte Tin |
Wire/Cable Type | UL 1061 |
Number of Rows | 1 |
Material - Metal | Copper Alloy |
Plating min - Mating | 0.889µm |
Color - Resin | Natural |
Pitch - Mating Interface | 2.50mm |
Circuits (Loaded) | 5 |
Termination Interface: Style | Crimp or Compression |
Voltage - Maximum | 250V AC (RMS)/DC |
Material - Plating Mating | Matte Tin |
Gender | Female-Female |
Overmolded | No |
Single Ended | No |
Current - Maximum per Contact | 3.5A |
Connector to Connector | Mini-Lock-to-Mini-Lock |
Assembly Configuration | Dual Ended Connectors |
Product Name | Mini-Lock |
