Shop All Terminal Blocks
Molex
Pluggable Terminal Blocks 5.0Mm Euro Header Ra O Header Ra Grn 7Ckt
Mfr # 395226007
Zoro # G105798779
product price: $1.85
/ea
Sold in multiples of 4800 for $8,880.00
$8,880.00
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Type Euro Block
- PC Tail Length 3.90mm
- Product Name ESE,Eurostyle Pluggable
- PCB Thickness - Recommended 3.20mm
- Polarized to Mating Part Yes
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Molex
- MFR # 395226007
- Zoro # G105798779
- Country of Origin Switzerland
- Category Terminal Blocks
Dimensions
PC Tail Length | 3.90mm |
Details
Type | Euro Block |
Product Name | ESE,Eurostyle Pluggable |
PCB Thickness - Recommended | 3.20mm |
Polarized to Mating Part | Yes |
Lock to Mating Part | Yes |
Circuits (Loaded) | 7 |
Stackable | No |
Component Type | PCB Header |
Pitch - Mating Interface | 5.00mm |
Current - Maximum per Contact | 15.0A |
Shrouded | Closed Ends |
Number of Rows | 1 |
UL | E48521 |
Voltage - Maximum | 300V |
Temperature Range - Operating | -40° to +105°C |
Series | 39522 |
Orientation | Horizontal |
