Shop All Hazardous Location Plugs
Molex
MPIS M12 NPN 4P 4PT BK 5M SINGLE
Mfr # 1202480007
Zoro # G2089741
product price: $134.99
/ea
Free Shipping & Returns
$134.99
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Home Run Interface Pigtail
- Poles 4
- Orientation Top Mount
- Cable Connector Orientation Straight
- Wiring Configuration Single I/O per Port
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
Product Information
- Brand Molex
- MFR # 1202480007
- Zoro # G2089741
- Country of Origin Unknown
- Category Hazardous Location Plugs
Dimensions
| Cable Length | 5.0m |
| Home Run Cable Length | 5.0m |
Details
| Home Run Interface | Pigtail |
| Poles | 4 |
| Orientation | Top Mount |
| Cable Connector Orientation | Straight |
| Wiring Configuration | Single I/O per Port |
| Functional Wiring | NPN |
| Poles (wired) | 4 |
| Material - Housing | PBT |
| Material - Cable Jacket | TPU |
| Material - Metal | Copper Alloy |
| Wire/Cable Type | WSOR |
| Voltage - Maximum | 10-30V DC |
| Keyway | A-coded |
| Ports | 4 |
| UL | E152210 |
| Current - Maximum per Contact | 12.0A per module, 4.0A per port |
| Temperature Range - Operating | -25°C to +85°C |
| Material - Plating Mating | Gold |
| LED Indicator | NPN Sensors |
| IP Rating | IP67 |
| Product Name | MPIS |
| Series | 120248 |
