Molex
KK2.5 Wafer Assy W/Lock 9Ckt
Mfr # 22-04-1091
Zoro # G2760332
product price: $1.69
/ea
Sold in multiples of 70 for $118.30
$118.30
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- PCB Thickness - Recommended 1.60mm
- Material - Plating Termination Tin
- Plating min - Termination 5.080µm
- Material - Resin Polyamide
- Current - Maximum per Contact 3.0A
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Molex
- MFR # 22-04-1091
- Zoro # G2760332
- Country of Origin China
- Category Hazardous Location Plugs
Dimensions
PC Tail Length | 3.40mm |
Details
PCB Thickness - Recommended | 1.60mm |
Material - Plating Termination | Tin |
Plating min - Termination | 5.080µm |
Material - Resin | Polyamide |
Current - Maximum per Contact | 3.0A |
Pitch - Mating Interface | 2.50mm |
Circuits (Loaded) | 9 |
Shrouded | Partial |
Durability (mating cycles max) | 30 |
Number of Rows | 1 |
Circuits (maximum) | 9 |
Voltage - Maximum | 250V |
Color - Resin | Natural |
Pitch - Termination Interface | 2.50mm |
UL | E29179 |
Termination Interface: Style | Through Hole |
Plating min - Mating | 5.080µm |
Lock to Mating Part | Yes |
Flammability | 94V-0 |
Material - Metal | Brass |
Material - Plating Mating | Tin |
Temperature Range - Operating | -40° to +105°C |
Orientation | Vertical |
