Molex
Kk 2.54 Sr R-S 10Ckt 300Mm Disc Sn
Mfr # 2177971102
Zoro # G005925954
product price: $5.69
/ea
Sold in multiples of 525 for $2,987.25
$2,987.25
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Series 217797
- Cable Length 300.00mm
- Type Discrete Wire Assembly
- Connector to Connector KK 254-to-Pigtail
- Pitch - Mating Interface 2.54mm
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Molex
- MFR # 2177971102
- Zoro # G005925954
- Country of Origin India
- Category Communication Cables
Dimensions
Cable Length | 300.00mm |
Wire Size (AWG) | 22 |
Wire Insulation Diameter | 1.57mm max. |
Details
Series | 217797 |
Type | Discrete Wire Assembly |
Connector to Connector | KK 254-to-Pigtail |
Pitch - Mating Interface | 2.54mm |
Material - Plating Termination | Tin |
Lock to Mating Part | Yes |
Product Name | KK 254 |
Gender | Female-Pigtail |
Assembly Configuration | Dual Ended Connectors |
Color - Resin | Natural (White) |
Number of Rows | 1 |
Circuits (Loaded) | 10 |
Wire/Cable Type | UL 11028 |
Material - Metal | Brass |
Material - Plating Mating | Tin |
Material - Resin | Nylon |
Termination Interface Style | Crimp or Compression |
Plating min - Mating | 2.540µm |
Single Ended | No |
