Shop All Hazardous Location Plugs
Molex
187X032 FE AQUA FIQD EXP TAPED BB-2208XT
Mfr # 19003-0061
Zoro # G2744381
original price:
$0.50
20% off
new price: $0.40
/ea
Sold in multiples of 750 for $300.00
$300.00
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- CSA LR18689
- Gender Female
- Material - Resin Nylon
- Material - Plating Mating Tin
- Barrel Type Closed
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Molex
- MFR # 19003-0061
- Zoro # G2744381
- Country of Origin United States
- Category Hazardous Location Plugs
Dimensions
Wire Size mm² | 1.30-2.00 |
Wire Size AWG | 14, 16 |
Tab Width | 4.75mm |
Wire Insulation Diameter | 6.60mm max. |
Details
CSA | LR18689 |
Gender | Female |
Material - Resin | Nylon |
Material - Plating Mating | Tin |
Barrel Type | Closed |
Voltage - Maximum | 600V |
Flammability | 94V-2 |
Orientation | Straight |
Tab Thickness | 0.81mm |
UL | E79133 |
Color - Resin | Blue |
Material - Plating Termination | Tin |
Material - Metal | Brass |
Plating min - Mating | 4.064µm |
Temperature Range - Operating | -65° to +105°C |
Insulation | Nylon (PA) |
Plating min - Termination | 4.064µm |
Termination Interface: Style | Crimp or Compression |
