UNDERCUTTER, LATHE-TYPE, 115V., 60 Hz., WITHOUT SLIDE CARRIAGE

The Lathe-Type Undercutter can be quickly attached in place of the tool post on any lathe. It can be mounted directly on the cross slide, or on the slide carriage which is then mounted on the cross slide. Both horizontal and vertical commutators can be undercut. As undercutting is done from the side of the commutator the saw or inVin cutter is set level with the lathe centers. Undercutter is powered by a 1/3 h.p. motor and uses high-speed steel or tungsten-carbide saw or inVin cutters. A spring between hardened washers under the pulley allows the spindle to move infloatin up or down and follow an existing slot that is being re-cut. If a fixed spindle is desired, the spring can be removed and the pulley turned over. There are two versions of the Lathe-Type undercutter available, depending on the amount of clearance needed to clear larger diameter risers. NEEDS TO BE PAIRED WITH AN AIR FILTER LUBRICATOR
