Watertight Connector, 5-20R, 20A, 125V

Name: Watertight Connector, 5-20R, 20A, 125V
Brand: Leviton
SKU: G3684284
Price: 54.99 USD
Availability: InStock

$54.99

/ea

Free Shipping on orders over $50

after you

Free 30-Day Returns

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Accepted Payment Options

Net 30

Product Information

Item - Plugs and Receptacles	Watertight Straight Blade Connector
Item	Watertight Straight Blade Connector
Wiring Style	Standard
Grade - Plugs and Receptacles	Industrial
Amps - Plugs and Receptacles	20
Voltage - Plugs and Receptacles	125VAC
NEMA Plug Configuration - Plugs and Receptacles	5-20R
Number of Wires	3
Antimicrobial	No
Color	Yellow
Number of Poles	2
HP	1.0
Standards	UL/CSA/NOM/NEMA WD-6/ANSI C-73
Grade	Industrial
NEMA Configuration	5-20R
Material	Ethylene Propylene Thermoplastic Rubber
Special Features	Corrosion resistant
Phase	1
IP Rating	67
Voltage	125VAC
Color - Plugs and Receptacles	Yellow
Amps	20
Corrosion Resistant	Yes
Type	Watertight Connector;Straight Blade
Power Indicator	No
Bushing Material	Santoprene TPV
Temp. Rise	30°C
Flammability	UL 94 V2
Body Material	EPTR Rubber
Dielectric Strength	2000V
Screw Material	300 Stainless Steel
Contact Material	Nickel Plated Brass
Operating Temp.	-40 to 60°C
Environmental Conditions	Flammability (Rated V-2 per UL 94 (Wiring Module));Operating Temperature Range (-40 to +60 DEG C)
Enclosure	NEMA 4/4X/12/IP66/IP67
Voltage Rating	125 V
Temperature Rating	-40 to 60 °C
Cord Type	S;ST;SO;SOW
Mounting	Cable
Terminal Type	Screw
Standard	NEMA (WD-1, WD-6);ANSI (C-73);NOM Certified (057);CSA (C22.2 No.42);UL (498)
Connection	Screw Terminal
Amperage Rating	20 A

20 Amp, 125 Volt, Connector, Straight Blade, Industrial Grade, Grounding, Wetguard, Yellow
