Shop All Hydraulic Hose Fittings
Kurt
Crimp Fitting, 90 Degrees Elbow, 1/2" ID
Mfr # F-BSPX90-08-08
Zoro # G6416874
$32.45
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Fitting Shape 90 Degrees Elbow
- Hydraulic Fitting Connection Type Crimpable
- For Hose Dash Size -8
- For Use With Hose Series H017, H104, H145, H190, H245, H558
- For Hose I.D. 1/2 in
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
Product Information
- Brand Kurt
- MFR # F-BSPX90-08-08
- Zoro # G6416874
- Country of Origin United States
- Category Hydraulic Hose Fittings
Dimensions
For Hose Dash Size | -8 |
Fitting Size | 1/2 in x 1/2 in |
Thread Size | 1/2"-14 |
Barb Size | 1/2" |
Details
Item | Hydraulic Crimp Fitting |
Fitting Shape | 90 Degrees Elbow |
Hydraulic Fitting Connection Type | Crimpable |
For Use With Hose Series | H017, H104, H145, H190, H245, H558 |
For Hose I.D. | 1/2 in |
Hydraulic Hose I.D. | 1/2 in |
Fitting Connection Type | BSP x Hose End |
Finish | CLEAR ZINC PLATING |
Fitting Material | Carbon Steel |
Max. Working Pressure @ 70 F | 3,500 psi |
Description
Hydraulic Crimp Fitting, For Hose Dash Size -8, For Use With Hose Series H017, H104, H145, H190, H245, H558, For Hose I.D. 1/2 in, Thread Size 1/2 In.-14, Fitting Shape 90 Degrees Elbow, 3,500 psi, Fitting Material Carbon Steel
