Condensate Pump, 73 Watts, 10 in. L

Mfr # KL-1DG-277
Zoro # G3813848

$448.99

Free Shipping & Returns

Free Shipping on orders over $50

after you

Free 30-Day Returns

Key Features

Condensate Pumps - Type Plenum Rated
Reservoir Size - Pumps Small
Voltage 277
HP - Pumps 1/30 hp
Voltage - Pumps 277V AC

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Hartell
MFR # KL-1DG-277
Zoro # G3813848
UPC #
856472008095
Country of Origin United States
Category Condensate Pumps

Dimensions

Reservoir Size - Pumps	Small
Discharge Size - Pumps	3/8 in Barb
Cord Length	2.5 ft
Length	10 in
Width	5 1/2 in
Height	4 3/4 in
Overall Width	5.5 in
Overall Height	4.75 in
Overall Length	10 in
Compatible Intake Pipe Size	1 in, 1 3/4 in
Manufacturer Warranty Length	1 yr
Compatible Discharge Pipe Size	3/8 in

Details

Condensate Pumps - Type	Plenum Rated
Item	Condensate Removal Pump
Voltage	277
HP - Pumps	1/30 hp
Voltage - Pumps	277V AC
Reservoir Capacity - Pumps	1/4 gal
Max. Temp - Pumps	212 Degrees F
Max. Head - Pumps	18 ft
Shaft Material	Stainless Steel
Shut-Off	18 ft.
Includes	Thermal Overload Protector
GPH of Water @ 5 Ft. of Head	57
Pump Type	Low Profile, Plenum Rated
GPH of Water @ 40 Ft. of Head	0
Max. Temp.	212 Degrees F
Reservoir Capacity	1 qt.
Discharge	3/8" Barb
Standards	UL 2043 Plenum Rated
Float Material	Polypropylene
GPH of Water @ 9 Ft. of Head	46
Amps	0.53 A
GPH of Water @ 30 Ft. of Head	0
Watts	73 W
Max. Pressure	7.8 psi
HP	1/30
GPH of Water @ 20 Ft. of Head	0
GPH of Water @ 12 Ft. of Head	38
GPH of Water @ 15 Ft. of Head	26
GPH of Water @ 1 Ft. of Head	66
Max. Head Range	10 ft to 19 ft
Maximum Flow Rate @ 5 Feet of Head	1 gpm
Maximum Flow Rate @ 1 Feet of Head	1.1 gpm
Electrical Connection Type	Wire Leads
Discharge Connection	3/8 in Barbed
Nameplate Voltage	277V AC
Horsepower	1/30 hp
Maximum Flow Rate @ 15 Feet of Head	0.4 gpm
Maximum Flow Rate @ 10 Feet of Head	0.7 gpm
Body Gasket Material	Stainless Steel
Number of Intakes	2
Pump Activation Type	Float Switch
Maximum Ambient Temperature	212 Degrees F
Plenum Rated	Yes
Series	KL-1DG-277
Maximum Media Temperature	212 Degrees F
Maximum Flow Rate @ 50 Feet of Head	[DELETE]
Intake Connection	1 in Barbed
Maximum Operating Pressure	7.8 psi
Tank Capacity	1/4 gal
Maximum Feet of Head	18 ft
For Use With Potable Systems	No
Discharge Connection Style	Barbed
Intake Connection Style	Barbed
Series Family	KL
Compatible Media Type	Water

Description

Condensate Removal Pump, Discharge Connection Style Barbed, Horsepower 1/30 hp, Includes Thermal Overload Protector, Intake Connection Style Barbed, Maximum Feet of Head 18 ft, Maximum Flow Rate @ 10 Feet of Head 0.7 gpm, Maximum Flow Rate @ 15 Feet of Head 0.4 gpm, Maximum Flow Rate @ 1 Foot of Head 1.1 gpm, Maximum Media Temperature 212 Degrees F, Nameplate Voltage 277V AC, Plenum Rated Yes, Pump Type Low Profile, Plenum Rated, Series KL-1DG-277, Series Family KL, Tank Capacity 1/4 gal

Documents & Resources

Technical Guide Opens PDF in new window

Restrictions

*** This is a restricted item in CA, LA, MD, VT. It cannot be used for potable water applications.
