Shop All Straight Center Discharge Pumps

Pump, 1-1/2 HP, 3 Phase, Max. Head 135 ft.

Mfr # 100MS1F5B4
Zoro # G2473517

$1,444.99

Free Shipping & Returns

Free Shipping on orders over $50

after you

Free 30-Day Returns

Key Features

Discharge Pump Type Straight Center Discharge Pump
HP - Pumps 1 1/2 hp
Phase - Pumps 3
Voltage - Pumps 200 to 240/480V AC
Max. Pressure - Pumps 75 psi

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand Goulds Water Technology
MFR # 100MS1F5B4
Zoro # G2473517
UPC #
697666962461
Country of Origin United States
Category Straight Center Discharge Pumps

Dimensions

Inlet Size - Pumps	1-1/4 in NPT
Outlet Size - Pumps	1 in NPT
Manufacturers Warranty Length	1 yr
Width	8 1/2 in
Height	8 1/2 in
Cord Length	No Cord
Diameter	6 in
Cord Size	None
Length	12 in
Overall Length	12 in
Manufacturer Warranty Length	1 yr
Intake and Discharge Size	1 1/4 in , 1 in
Compatible Intake Pipe Size	1 1/4 in
Compatible Discharge Pipe Size	1 in
Overall Width	8.5 in
Overall Height	8.5 in

Details

Discharge Pump Type	Straight Center Discharge Pump
HP - Pumps	1 1/2 hp
Phase - Pumps	3
Voltage - Pumps	200 to 240/480V AC
Max. Pressure - Pumps	75 psi
Housing Material - Pumps	Stainless Steel
Motor Enclosure - Pumps	Totally Enclosed Fan-Cooled
Best Efficiency Range GPM @ Head	38 to 42 gpm @ 105 to 95 ft
GPM of Water @ 110 Ft. of Head	126
Cord Type	None
Bearing Type	Ball
Amps	4.4-4.2/2.1
Motor RPM	3,500 RPM
GPM of Water @ 120 Ft. of Head	19
Best Efficiency GPM @ PSI	35 @ 43
Impeller Material	Stainless Steel
GPM of Water @ 90 Ft. of Head	42
Installation Position	Horizontal
Seal Material	316 Stainless Steel, Carbon, Silicon Carbide, Viton
Max. Head	135 ft
GPM of Water @ 80 Ft. of Head	47
GPM of Water @ 130 Ft. of Head	80
Max. Case Pressure	75 psi
Overload Protection	No
Inlet Pressure	3 psi
Agency Compliance	NSF 61
Wetted Materials	316 Stainless Steel, Carbon, Silicon Carbide, Viton
Max. Liquid Temp.	212 Degrees F
Max. Specific Gravity	1.0
Motor Ambient Temp. Rating	40 Degrees C
Duty	Continuous
Thermal Protection	No
Motor Type	Totally Enclosed Fan-Cooled
Impeller Type	Closed
GPM of Water @ 100 Ft. of Head	35
Item	Centrifugal Pump
Port Rotation	45 Degrees Increments
Hz	60
Frame	56
Phase	Three
Motor Enclosure	Totally Enclosed Fan Cooled (TEFC)
Best Efficiency Flow	36 gpm
Specific Gravity (Maximum)	1
Flow Rate @ 80 ft of Head (Maximum)	46 gpm
Standards	NSF 61 Certified
Mounting Orientation	Horizontal
Electrical Connection Type	Hardwired
Nominal Voltage	208-230/460V AC
Priming	Manual
Thermal Overload Protection	No
Motor Frame Designation	56
Flow Rate @ 100 ft of Head (Maximum)	35 gpm
Intake Type	NPT
Discharge Type	NPT
Flow Rate @ 90 ft of Head (Maximum)	40 gpm
Duty Cycle	Continuous
Flow Rate @ 120 ft of Head (Maximum)	19 gpm
Nameplate Voltage	208-230/460V AC
Horsepower	1 1/2 hp
Wetted Material	316 Stainless Steel, Carbon, Silicon Carbide, Viton
Best Efficiency Head	100 ft
Impeller Design	Closed
Frequency	60 Hz
Maximum Feet of Head	136 ft
Motor Enclosure Type	TEFC
Shut Off Pressure (Maximum)	75 psi
For Use With Potable Systems	No
Discharge Rotation	45 Degrees Increments
Maximum Media Temperature	212 Degrees F
Pump Housing Material	Stainless Steel
Compatible with Media Type	Water
Maximum RPM	3,500 RPM

Description

Centrifugal Pump, Phase Three, Pump Housing Material Stainless Steel, Horsepower 1 1/2 hp, Nameplate Voltage 208-230/460V AC, Flow Rate @ 80 ft of Head (Maximum) 46 gpm, Maximum Feet of Head 136 ft, Compatible Intake Pipe Size 1 1/4 in, Intake Type NPT, Compatible Discharge Pipe Size 1 in, Discharge Type NPT, Motor Enclosure Totally Enclosed Fan Cooled, Flow Rate @ 100 ft of Head (Maximum) 35 gpm, Flow Rate @ 120 ft of Head (Maximum) 19 gpm, Priming Manual

Restrictions

*** This is a restricted item. It cannot be used in the USA for potable water applications.
