Shop All General Purpose Relays
Functional Devices-Rib
Universal Voltage Power Pack, Input 120-277Vac, Output 24Vac-Class 2
Mfr # LR21BPP5
Zoro # G1801940
original price:
$79.97
14% off
new price: $68.39
/ea
$68.39
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Width 3.2
- Voltage 120-277Vac
- Amps 20 Amp
- Dimensions 2.39"H x 3.31"W x 1.81"D with 0.75" NPT nipple
- Length 2.3
Get 10% Off Your First Order
Real Support From Real People
Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
![paypal](https://www.zoro.com/static/assets/img/base/icons/paypal-81447b0e73.png)
Product Information
- Brand Functional Devices-Rib
- MFR # LR21BPP5
- Zoro # G1801940
- Country of Origin United States
- Category General Purpose Relays
Dimensions
Width | 3.2 |
Dimensions | 2.39"H x 3.31"W x 1.81"D with 0.75" NPT nipple |
Length | 2.3 |
Details
Voltage | 120-277Vac |
Item | Universal Power Pack |
Amps | 20 Amp |
Color | Gray |
Operating Temperature | -30 to 104° F |
Momentary Override | Yes |
Power Status | Green LED On - 24Vdc out |
Expected Relay Life | 10 million cycles minimum mechanical |
DC Output | 24 Vdc @ 210mA, Class 2 |
Approvals | UL Listed, UL916, C-UL, CE |
Wires | 16", 600V Rated |
Power Input | 250 mA @ 120 -277 Vac |
No. of Relays & Contact Type | One (1) SPDT Continuous Duty Coil |
Humidity Range | 5 to 95% (noncondensing) |
Housing Rating | UL Accepted for Use in Plenum, NEMA 1 |
Gold Flash | No |
Operate Time | 1.8 Seconds |
Contact Ratings | 20 Amp Resistive @ 277 Vac 5 Amp Resistive @ 480 Vac 20 Amp Ballast @ 277 Vac 16 Amp Electronic Ballast @ 277 Vac (N/O) 10 Amp Tungsten @ 120 Vac (N/O) 770 VA Pilot Duty @ 120 Vac (N/C) 1100 VA Pilot Duty @ 277 Vac (N/C) 2 HP @ 277 Vac 1 HP @ 120 Vac |
Relay Status | Red LED On - Activated |
Description
Universal Voltage Power Pack, Input 120-277Vac, Output 24Vac-Class 2, 5-Watt at 210mA max.; SPDT relay with Momentary Switch, 10A; 120Vac Incand, 20A; 277Vac Bal and 16A; 277Vac EB ratings; NEMA 1, UL Accepted Plenum Rated Enclosure
