  11. RC251, 25.8 ton Capacity, 1.00 in Stroke, General Purpose Hydraulic Cylinder
Shop All Single Acting Hydraulic Cylinders
Enerpac

RC251, 25.8 ton Capacity, 1.00 in Stroke, General Purpose Hydraulic Cylinder

product price: $944.00
/ea
Free Shipping & Returns
Not eligible for select promotions
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Handle No
  • Max. Pressure 10,000 psi
  • Bolt Circle Dia. 2.31"
  • Collar Thread Size 3-5/16"-12
  • Extended Height 6.5 in
See all product information
Get 10% Off Your First Order
Real Support From Real People Contact Our U.S.-Based teams
Free 30-Day Returns
Return Policy
Accepted Payment Options
visa mastercard american express discover paypal
Net 30

Product Information

Dimensions

Bolt Circle Dia. 2.31"
Collar Thread Size 3-5/16"-12
Extended Height 6.5 in
Thread Size 1/2"-13
Outside Dia. 3.38 in
Stroke Length 1 in
Plunger Thread Size 1-1/2"-16
Center Hole Dia. 2 1/4 in
Plunger Dia. 2.25 in
Retracted Height 5.5 in
Nominal Stroke Length 1 in
Base Bolt Circle Dia. 2.31 in

Description

Hydraulic Ram, Single Acting, General Purpose, Steel, Nominal Capacity 25 ton, Max. Push Capacity 25 ton, Stroke Length 1 in, Nominal Stroke Length 1 in, Effective Push Area 5.16 sq in, Max. Pressure 10,000 psi, Oil Capacity Push 5.16 cu in, Retracted Height 5.5 in, Extended Height 6.5 in, Outside Dia. 3.38 in, Plunger Dia. 2.25 in, Plunger Thread Size 1-1/2 In.-16, Collar Thread Size 3-5/16 In.-12, Base Bolt Circle Dia. 2.31 in, Center Hole Dia. 2 1/4 in, Series RC, Includes Coupler, Dust Cap
