Hot Melt Adhesive, DP190 Series, White, Dual-Cartridge, 12 PK, 1:01 Mix Ratio, 12 hr Functional Cure

Mfr # 190
Zoro # G5993321

$903.99

/pk 12, $75.33/ea

Free Shipping & Returns

Free Shipping on orders over $50

Free 30-Day Returns

Key Features

Type Duo-Pak
Application For use in the EPX Plus Applicator
Color White
For Use On Applicator, Mixing Tip
Container Type Dual-Cartridge

See all product information

Get 10% Off Your First Order

Real Support From Real People Contact Our U.S.-Based teams

Free 30-Day Returns

Return Policy

Accepted Payment Options

Net 30

Product Information

Brand 3M
MFR # 190
Zoro # G5993321
UPC #
00021200878381
Country of Origin United States
Category Epoxy & Structural Adhesives

Dimensions

Size

6.76 oz

Details

Item	Hot Melt Adhesive
Type	Duo-Pak
Application	For use in the EPX Plus Applicator
Color	White
For Use On	Applicator, Mixing Tip
Container Type	Dual-Cartridge
Functional Cure	12 hr
Full Cure	14 day
Mixing Ratio	1:01
Shear Strength	1,200 psi
Temp. Range	-65 Degrees to 300 Degrees
Working Time	80 min
Series	DP190
Work Life	1 hr
Structural Adhesive Type	Epoxy Adhesive
Epoxy Color	Clear
Temp. Range (F)	-65 Degrees to 300 Degrees
Epoxy Container	Dual-Cartridge
Epoxy Max. Temp	300 Degrees F and Above
Shear Strength (PSI)	1,800
Includes	Resin and Hardener
Green Environmental Attribute	Does Not Contain Methylene Chloride
Coverage	320 sq ft/gal
For Use With	Applicator, Mixing Tip
Resin Type	Epoxy
Application Method	No Special Application
Peel Strength	20 lb/in
VOC Content Weight Percentage	Less Than 0.5%
Interior/Exterior	Interior/Exterior
Consistency	Paste
VOC Content Range	Under 5 g/L
Features	Flexible, High Shear and Peel Strength
Tensile Strength	1,200 psi
Compatible Applicator	3M EPX
Maximum Application Temperature	80 Degrees F
Compatible Mixer Tip	3M EPX
Cure Method	Ambient
Compatible Accelerator	Scotch-Weld 2216
Compatible Applicator (Grainger Part Number)	794HJ1
Total Volume Range	51 to 200 mL
Materials Bonded	Ceramic, Fiberglass, Glass, Metal, Plastic, Rubber, Wood
Hardness at Full Cure	60 Shore D
Brand & Series	3M DP190
Primary Application	For General Purpose
Non-Sagging	No
VOC Content Weight	Less Than 5 g/L
Standards	UL 94 HB
Cured Color	Translucent
Shear Strength Range	1000 to 2000 psi
Water Resistance	Not Water-Resistant
Secondary Compatible Materials	Ceramic and Porcelain, Glass and Fiberglass, Metals, Plastics, Rubber, Wood
Primary Applications	General Purpose
Max Visc and Text Consistency	100,000 cps
Total Volume	200 mL
Included Components	Resin and Hardener
Compatible Primer	EC-3901 for Glass
Low Odor	No
Full Cure Time	14 day
Maximum Viscosity	100,000 cps
Working Time Range	26 min to 80 min
Color Family	Clear
Minimum Performance Temperature	-65 Degrees F
Marine Grade	No
Maximum Performance Temperature	180 Degrees F
Total Vol plus Container Type	200 mL Dual-Cartridge
Container Type - Adhesives	Dual-Cartridge

Description

Epoxy Adhesive, Compatible Applicator 3M EPX, Compatible Mixer Tip 3M EPX, Compatible Primer EC-3901 for Glass, Container Type Dual-Cartridge, Coverage 320 sq ft/gal, Cure Method Ambient, Cured Color Translucent, Features Flexible, High Shear and Peel Strength, For Use With Applicator, Mixing Tip, Included Components Resin and Hardener, Interior/Exterior Interior/Exterior, Low Odor No, Marine Grade No, Materials Bonded Ceramic, Fiberglass, Glass, Metal, Plastic, Rubber, Wood
