Shop All Pump Parts
Zoro Select

Flanges

product price: $644.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Flange Outside Diameter 14 in
  • Fitting Connection Type Blind
  • Number of Bolt Holes 12
  • Standards ASME B16.5/ ASTM A182
  • Color Silver
See all product information

Product Information

Dimensions

Flange Outside Diameter 14 in
Overall Length 12 1/2 in
Thread Size Non-Threaded
Bolt Hole Diameter 7/8 in
Nominal Pipe Size 6 in
Bolt Circle Diameter 10 5/8 in

Details

Item 6 in 316Lss Blind Flange 300#
Fitting Connection Type Blind
Number of Bolt Holes 12
Standards ASME B16.5/ ASTM A182
Color Silver
Pipe Fitting Material Stainless Steel
Specific Fitting Shape Blind Flange
Temp. Range -10-1000 Degrees F
For Pipe Schedule 40
Maximum Operating Pressure 600 psi
Application Air, Natural Gas, Non-Potable Water, Potable Water, Propane, Steam
Max. Steam Pressure 840 psi @ 400 Degrees F
Material Grade 316L
Class Class 300
Flange Thickness 1 3/8 in
Low Lead Compliance Level Compliant
Finish/Coating Stainless Steel
Connection Surface Raised Face

Description

Blind Flange, Raised Face, 6 in Nominal Pipe Size, Blind, 14 in Flange Outside Diameter, 1 3/8 in Flange Thickness, 12 1/2 in Overall Length, Stainless Steel, Stainless Steel, 316L, Class Class 300, For Pipe Schedule 40, 600 psi Maximum Operating Pressure, 840 psi @ 400 Degrees F Max. Steam Pressure, -10-1000 Degrees F, Number of Bolt Holes 12, 10 5/8 in Bolt Circle Diameter, 7/8 in Bolt Hole Diameter

Restrictions

  • *** This is a restricted item in CA, LA, MD, VT. It cannot be used for potable water applications.
