Professional Plastics

Gray PET Ertalyte TX Rod (Q), 1.000 Dia [Ft]


product price: $93.89
/ea
Free Shipping & Returns

Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Weight 1
  • Height 1
  • Length 12
  • Material Ertalyte
  • Color Gray
See all product information

Product Information

Dimensions

Height 1
Length 12
Width 1

Details

Weight 1
Material Ertalyte
Color Gray
Flexural Strength (psi @ 73 Deg: F) 14000
Tensile Elongation at Break (% @ 73 Deg: F) 5
UL94 Flammability Rating Method: UL 94 H-B
CoLT Expansion (x 10-5 in./in./Deg:F) 4.5
Specific Gravity (73 Deg: g/cm3) 1.44
Heat Deflection Temp. (264 psi) Deg:F 180
Tensile Strength (psi @ 73 Deg;) 10500
USDA Compliant Yes
Thermal Conductivity (BTU-in/ft²-hr-°F) 1.9
Max. Recommended Use Temp (Deg:F) 210
FDA Compliant Yes
3A Dairy Compliant Yes

Description

Ertalyte® TX for machining high-wear-resistant parts is an unreinforced semi-crystalline thermoplastic polyester (PET-P) that has a solid lubricant filler. The material has excellent performance in both high-pressure and high-velocity conditions, and is ideally suited for applications involving soft metal and plastic mating surfaces. Key properties of Ertalyte TX, are its high strength and stiffness, high wear-resistance, very good dimensional stability, high creep resistance and very good chemical resistance. This combination of properties make it an ideal material for machining bushings and bearings that require no startup or running lubrication. Ertalyte TX has FDA and USDA compliance and is ideal for applications in food packaging and processing equipment. Ertalyte TX shapes offer dimensional stability, wear resistance, and low-friction characteristics superior to those properties of competitive filled polyethylene terephthalate polymers. Excellent replacement for full-strength Delrin® AF, when parts require food contact. Standard Sheet Size: 24" x 39.4" Standard Rods: 10 Foot (may be cut in-half for FedEx or UPS Shipping to save freight) - add Shipping Note at Check-Out or Call for Assistance

Restrictions
