9 in. Diecast, Casement Operator, Left Hand, Square Type (Single Pack)
Mfr # H 3710
Zoro # G0599300
$18.79
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Finish Bronze
- Material Steel
- Length (In.) 9 in.
- Height (In.) 13 1/4 in
- Base Size (In.) 4-3/4
Product Information
- Brand Primeline Tools
- MFR # H 3710
- Zoro # G0599300
- UPC # 49793037107
- Country of Origin China
- Category Window Operators & Covers
Dimensions
Length (In.) | 9 in. |
Height (In.) | 13 1/4 in |
Base Size (In.) | 4-3/4 |
Width (In.) | 3-29/32 |
Details
Finish | Bronze |
Material | Steel |
Strike (In.) | 13-7/8 |
Projection (In.) | 11/16 in |
Type | Square Housing |
Item | Left Hand Window Operator |
Includes | Mounting Hardware |
Color | White |
Hardware | Included |
Description
This casement window operator is a left-handed bronze square body type. It has a 9 inch steel arm with a round disc on the tip (some older styles had a small wheel instead of a disc). The disc slides in the Prime-Line part H 3529 casement track located on the bottom of the casement window. It is worm gear driven by a 3/8 inch crank spindle. The matching crank handle that fits onto the crank spindle and installation screws are included. Mounting holes available are 3-7/8 inch and 4-3/4 inch apart.
- •Left handed square body crank handle (viewed from inside looking out)
- •Mounting holes are 3-7/8 inch and 4-3/4 inch on center
- •Arm is 9 inch from middle of the guide button to the middle of the crank operator while closed
- •Heavy duty diecast zinc construction with a white finish
- •Steel worm drive gear for durability
- •Matching crank handle is included
- •A Phillips head screwdriver is required for installation
- •Please refer to the line art drawing and compare with your original item before purchasing
