Shop All Compression Tube Fittings
Parker

1/4" Compression 316 SS Union

product price: $19.75
/ea
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Tube Fitting Material 316 Stainless Steel
  • Specific Fitting Shape Straight Connector
  • Fitting Connection Type Compression
  • Tube Size 1/4 in
  • Temp. Range -425 Degrees to 1200 Degrees F
See all product information

Product Information

Dimensions

Tube Size 1/4 in
Compression Thread Size 7/16-20
Overall Length 1 3/16 in
Hex Size 1/2 in
Thread Size A 7/16-20
Fitting Side A Tube Outer Diameter 1/4 in
Fitting Side B Tube Outer Diameter 1/4 in
Thread Size B 7/16-20
Length 1.19"
Thread Size 7/16-20

Description

Union, Application Gases, Hydraulic Fluids, Fitting Side A Connection Type Male Flareless Bite, Fitting Side B Connection Type Male Flareless Bite, Fitting Material Stainless Steel, Fitting Side A Tube Outer Diameter 1/4 in, Fitting Side B Tube Outer Diameter 1/4 in, Material Grade 316, Maximum Operating Pressure 6,000 psi, Maximum Operating Temperature 1,200 Degrees F, Overall Length 1 3/16 in, Specific Fitting Shape Straight Connector, Compatible Fitting Brands Ferulok, Thread Size A 7/16-20

Restrictions

  • *** This is a restricted item in CA, LA, MD, VT. It cannot be used for potable water applications.
