Shop All Filter, Regulator, Lubricator
Numatics

Filter Lubricator Assembly, Cap. 90 mL

product price: $287.99
/ea
Free Shipping & Returns
Free Shipping on orders over $50
Free 30-Day Returns

Key Features

  • Includes ASSEMBLED, Lubricator - 8652AL0P40A0000, Particulate Filter - 8652ABBP4JA000N, Regulator - 8652AR004FA00H0
  • Overall Height 10 11/16 in
  • Drain Type Manual - Semi-automatic Drain
  • Filter Rating 5 micron
  • Overall Width 7 13/16 in
See all product information

Product Information

Dimensions

Overall Height 10 11/16 in
Overall Width 7 13/16 in
Air Outlet Size 1/2 in
Overall Depth 2 7/8 in
Air Inlet Size 1/2 in
Pressure Gauge Port Size 1/2 in

Description

Filter/Regulator/Lubricator Assembly, Air Inlet Size 1/2 in, Air Inlet Type NPT, Maximum Flow Rate 2,290 lpm, Maximum Operating Pressure 10 bar, Filter Rating 5 micron, Filter Bowl Material Polycarbonate, Filter Bowl Capacity 60 mL, Lubricator Bowl Capacity 90 mL, Drain Type Manual - Semi-automatic Drain, Overall Width 7 13/16 in, Series 652, Adjustment Location Top, Adjustment Mechanism Knob, Adjustment Mechanism Material Plastic, Air Flow Direction Left to Right, Air Inlet Gender Male
