Time Delay Relay, 120VAC/DC, 10A, DPDT, 2VA

Mfr # TR-50222-04
Zoro # G5234311

$31.85

Free Shipping on orders over $50

Free 30-Day Returns

Key Features

Function - Timing Relay On Delay
Coil Volts 120V AC/DC
AC Contact Rating - Relay 10A @ 240V
DC Contact Rating - Relay 10A @ 30V
Base Type - Plug In Relay Octal

See all product information

Product Information

Brand Macromatic
MFR # TR-50222-04
Zoro # G5234311
UPC #
801262043138
Country of Origin United States
Category Time Delay Relays

Dimensions

Body Height - Relay	2.9 in
Body Depth - Relay	1.7 in
Overall Height - Relay	3.1 in
Body Width - Relay	2.4 in
Body Width	2.3 in
Overall Depth	3.5 in
Body Height	1.7 in
Body Depth	2.9 in

Details

Item - Relay	Single Function Timing Relay
Function - Timing Relay	On Delay
Coil Volts	120V AC/DC
AC Contact Rating - Relay	10A @ 240V
DC Contact Rating - Relay	10A @ 30V
Base Type - Plug In Relay	Octal
Number of Pins - Relay	8
Adjustment Method - Timer	Potentiometer
Mounting - Relay	Plug In
Min. Time Setting - Timer	0.05 sec
Contact Form - Relay	DPDT
Max. Time Setting - Timer	5 sec
Power Consumption - Relay	2 W, 2.5 VA
Contact Amp Rating (Resistive)	10A
Coil Rating	2VA
Operating Functions	1
Hz	50/60
Pins	8
Base Type	Octal
Item	Single Function Time Delay Relay
Socket	1EGP3, 1EGP5, 5X852
Socket Code	A
Hz - Electrical	50 Hz, 60 Hz
Adjustment Method	Potentiometer
Electrical Connection	Socket
Function	On Delay
Status Indicator	None
Contact Form	DPDT
Contact Material	Silver Nickel
Mounting	plug In
Standards	CE Certified, CSA Certified, UL Listed, UL Socket
Min. Time Setting	0.05 sec.
Max. Time Setting	5 sec.
Output	10A DPDT
Input Voltage	120V AC/DC
Base Shape	Octal
Sealing	Enclosed
Maximum Operating Temperature	122 Degrees F
Maximum Switching Voltage	240V AC
Number of Pins	8
Reset Method	Time-Limit Reset
Maximum Time Setting	5 sec
Frequency	50/60 Hz
IP Rating	IP20
Delay Function	On Delay
Electrical Operating Durability	100,000
Power Consumption	2 VA
Adjustment Interface	Analog
Mounting Style	Plug-In
Operating Time Accuracy	+2% 50ms
Current Rating	10 A
Minimum Time Setting	0.05 sec
Contact Rating (AC)	10 A @ 240V
Mechanical Operating Durability	10,000,000
Minimum Operating Temperature	-18 Degrees F
Number of Delay Functions	1
Coil Voltage	120V AC/DC
Contact Rating (DC)	10 A @ 30V
Control Voltage	120V AC/DC
Mount	Plug-in
Configuration / Contact Rating	DPDT & SPDT. 10A @ 240V AC/30V DC, 1/2HP @ 120/240V AC (N.O.),1/3HP @ 120/240V AC (N.C.), B300 & R300
Maximum Setting (Adjustable)	+5%, -0%;
Temperature	-28Â°to 65Â°C (-18Â°to 149Â°F)
Timing Range	0.05 - 5 seconds
Reset Time	0.1 Seconds
Voltage Tolerance	AC Operation: +10/-15% of nominal at 50/60 Hz.; DC Operation: +10/-15% of nominal.
Timing Adjustment	Analog
Minimum Setting (Adjustable)	+0%, -50%.
Load (Burden)	2 VA
Repeat Accuracy (Constant Voltage & Temperature)	+1% or 50ms, whichever is greater
Life	Mechanical: 2,000,000 operations; Full Load: 100,000 operations
Output Contacts	10A @ 240V AC, 8A @ 28V DC, 1/2HP @ 240V AC, 1/4HP @ 120V AC, B300 & R300
Enclosure Style	Plug-in case utilizing industry-standard 8 or 11 pin octal sockets
Fixed	+2% or 100ms, whichever is greater
