Shop All Gate Operators & Accessories
Linear
Slide Gate Operator
Mfr # GPX-SL25
Zoro # G8223941
product price: $1,153.99
/ea
Free Shipping & Returns
$1,153.99
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Type Single Gate - Light to Medium Duty
- For Use With 13X164, 13X165, 13X167, 13X176
- Includes AC Transformer, Battery Backup, Entry Transmitter, Gate Operator, Mounting Hardware, Radio Receiver
- Max. Capacity 24 ft Gate, 650 lb
- Cycle 1 ft per Second to Open
Product Information
- Brand Linear
- MFR # GPX-SL25
- Zoro # G8223941
- UPC # 090835006476
- Country of Origin China
- Category Gate Operators & Accessories
Dimensions
Height | 12 1/2 in |
Compatible Gate Maximum Length | 24 ft |
Overall Height | 12 1/2 in |
Details
Item | Slide Gate Operator |
Type | Single Gate - Light to Medium Duty |
For Use With | 13X164, 13X165, 13X167, 13X176 |
Includes | AC Transformer, Battery Backup, Entry Transmitter, Gate Operator, Mounting Hardware, Radio Receiver |
Max. Capacity | 24 ft Gate, 650 lb |
Cycle | 1 ft per Second to Open |
Safety Features | Adustable Obstruction Sensing, Auto Close, Gate Sequencing, Internal Friction Disc Brake/Lock, Manual Chain Release |
Voltage | 12V DC Rechargeable Battery |
Standards | ETL, UL 325 5th Edition |
Gate Operating Speed | 1 Foot Per Second |
Compatible Gate Type | Single Slide |
Maximum Operating Temperature | 120 Degrees F |
Power Source | Solar |
Minimum Operating Temperature | -5 Degrees F |
Maximum Motor Horsepower | 1/4 hp |
Features | Lift Quick Release Pins Up, then Pull them Out of Chain Brackets |
Compatible Gate Maximum Capacity | 650 lb |
Description
Slide Gate Operator, Overall Height 12 1/2 in, Operating Voltage 12V DC, Includes AC Transformer, Battery Backup, Entry Transmitter, Gate Operator, Mounting Hardware, Radio Receiver, Gate Operating Speed 1 Foot Per Second, Power Source Solar, Maximum Motor Horsepower 1/4 hp, Features Lift Quick Release Pins Up, then Pull them Out of Chain Brackets, Minimum Operating Temperature -5 Degrees F, Maximum Operating Temperature 120 Degrees F, Compatible Gate Type Single Slide
