Shop All Rotary Encoders
This Product is Discontinued
Durant
Encoder, Quadrature, 6000 RPM, 120 pulses (Discontinued)
Mfr # 38151120
Zoro # G3239372
Free Shipping & Returns
This Product is Discontinued
Key Features
- Input Voltage 5 to 28V DC
- Pulses per Revolution 120
- Output Type Quadrature
- Shaft Dia. 3/8 in
- Shaft Rotation CW/CCW
Product Information
- Brand Durant
- MFR # 38151120
- Zoro # G3239372
- Country of Origin United States
- Category Rotary Encoders
Dimensions
| Shaft Dia. | 3/8 in |
Details
| Item | Encoder |
| Input Voltage | 5 to 28V DC |
| Pulses per Revolution | 120 |
| Output Type | Quadrature |
| Shaft Rotation | CW/CCW |
| Speed | 6,000 RPM |
| Temp. Range (F) | 32 Degrees F to 167 Degrees F |
| Accuracy | +/-0.1 Degrees |
| Operating Life | Up To 100,000 hr Depending On Speed |
| Standards | UL,CSA |
| Mounting | Bottom/Front Face |
| For Use With | Totalizers and Counters |
| Ripple | Less Than or Equal To 2% |
| Pulse Rate | 1 to 10,000 Pulses/Sec |
| Current Rating (mA) | 60 Nom, 100 Max |
| Housing | Aluminum w/ Black Anodized Finish |
| Features | Sealed Against Dust, Oil, Vapor,and Moisture |
Description
Encoder, Quadrature, Input Voltage 5-28VDC, Current Rating 60 Nom., 100 Max. mA, Accuracy +/- 0.1 Deg., 1 to 10,000 Pulses/Sec, Pulses Per Revolution 120, Ripple Less Than or Equal To 2%, Operating Life Up To 100,000 hr Depending On Speed, Temp. Range 32-167 F, Speed 6000 RPM Max., Shaft Rotation CW/CCW, Shaft Dia. 3/8 In., Housing Aluminum w/ Black Anodized Finish, Mounting Bottom/Front Face, For Use With Totalizers and Counters, Sealed Against Dust, Oil, Vapor, and Moisture, Standards UL/CSA
