Shop All Relay Accessories
Crydom
Input/Output Relay, 50mA, Plug-In, White
Mfr # IDC5
Zoro # G1743813
product price: $23.29
/ea
$23.29
Free Shipping on orders over $50
after you
Free 30-Day Returns
Key Features
- Input or Control Voltage 4 to 32V AC/DC
- Output or Controlled Voltage Range 3 to 30V DC
- Case Color White (DC Input); Yellow (AC Input)
- Type of Output Solid State
- Mounting - Relay Printed Circuit Board
Product Information
- Brand Crydom
- MFR # IDC5
- Zoro # G1743813
- Country of Origin Mexico
- Category Relay Accessories
Dimensions
Body Depth - Relay | 0.6 in |
Overall Height - Relay | 1.49 in |
Body Width - Relay | 1.7 in |
Body Height - Relay | 1.25 in |
Body Depth | 0.4 in |
Body Height | 1 in |
Body Width | 1.7 in |
Overall Depth | 1.49 in |
Description
Input Module, Contact Form SPST-NO, Input Current 34 mA, Output Current 50 mA, Input Voltage 3.3 to 32V AC/DC, Output Voltage 30V DC, Number of Pins 5, Mounting Style Plug-In, Body Depth 0.4 in, Body Height 1 in, Body Width 1.7 in, Case Color White (DC Input); Yellow (AC Input), Features Open-Collector Output, Input Resistance 500 ohm, Isolation Voltage 4kV, Maximum Operating Temperature 176 Degrees F, Maximum Turn-Off Time 1 msec, Maximum Turn-On Time 1 msec
