Shop All Hose Reel Accessories
Coxreels
Swivel, 90 Deg., Brass, 1/4 in FNPT Inlet
Mfr # 8550
Zoro # G5997562
product price: $165.99
/ea
Free Shipping & Returns
$165.99
Free Shipping on orders over $50
after youÂ
Free 30-Day Returns
Key Features
- Includes Welding Hose Adapters in Inlet
- Material Brass
- Inlet Type NPT
- For Use With Mfr. Model Number 112W-1-100, 112W-1-50, 112WL-1-100, 112WL-1-50, 112WT-1-100, 112WT-1-50, 112WTL-1-100, 112WTL-1-50, 117W-1-200, 117WL-1-200, 117WT-1-200, 117WTL-1-200
- Minimum Operating Pressure 0 psi
Product Information
- Brand Coxreels
- MFR # 8550
- Zoro # G5997562
- Country of Origin United States
- Category Hose Reel Accessories
Dimensions
Outlet Thread Size | 1/8 in - 27 |
Inlet Thread Size | 1/4 in - 18 |
Details
Includes | Welding Hose Adapters in Inlet |
Material | Brass |
Item | Swivel |
Inlet Type | NPT |
For Use With Mfr. Model Number | 112W-1-100, 112W-1-50, 112WL-1-100, 112WL-1-50, 112WT-1-100, 112WT-1-50, 112WTL-1-100, 112WTL-1-50, 117W-1-200, 117WL-1-200, 117WT-1-200, 117WTL-1-200 |
Minimum Operating Pressure | 0 psi |
Outlet Swivel Configuration | 1/8 in FNPT |
Includes Seal | Yes |
Maximum Operating Temperature | 400 Degrees F |
Outlet Type | NPT |
Inlet Gender | Female |
Maximum Operating Pressure | 200 psi |
Outlet Gender | Female |
Angle | 90 Degrees |
Vacuum Rating | 29 in Hg |
Inlet Swivel Configuration | 1/4 in FNPT |
For Reel Series | 100W |
Seal Material | FKM |
Minimum Operating Temperature | -15 Degrees F |
Description
Swivel, For Use With Mfr. Model Number 112W-1-100, 112W-1-50, 112WL-1-100, 112WL-1-50, 112WT-1-100, 112WT-1-50, 112WTL-1-100, 112WTL-1-50, 117W-1-200, 117WL-1-200, 117WT-1-200, 117WTL-1-200, For Reel Series 100W, Material Brass, 90 Degrees , 200 psi, 0 psi, Inlet Type NPT, Inlet Gender Female, Inlet Thread Size 1/4 in - 18, Outlet Type NPT, Outlet Gender Female, Outlet Thread Size 1/8 in - 27, Includes Seal Yes, Seal Material FKM, -15 Degrees F, 400 Degrees F, 29 in Hg
Restrictions
- WARNING: Cancer and Reproductive Harm For more information go to www.P65Warnings.ca.gov
